HCD/HMD/HCF/HMF1810RHS, HCD/HMD/HCF/HMF2110RHS,
HCD/HMD1810NHS, HCD/HMD2110NHS
(See model number configurator on page 2 for details.)
Order parts online
www.follettice.com
and most countertop dispensers manufactured by
Horizon Elite
Ice Machine Models with RIDE
™
For applications using 110CM Symphony Plus
Cornelius • Lancer • SerVend
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Installation Instructions for Harmony
110CM Symphony
Technology
®
™
Plus Applications
™
remote condensing
01157866R03
or
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Horizon Elite HCD1810RHS
Summary of Contents for Follett Horizon Elite HCD1810RHS
- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ® Installation Instructions for Harmony ™ 110CM Symphony Plus Applications ™ HCD/HMD/HCF/HMF1810RHS, HCD/HMD/HCF/HMF2110RHS, HCD/HMD1810NHS, HCD/HMD2110NHS (See model number configurator on page 2 for details.) Order parts online www.follettice.com remote condensing For applications using 110CM Symphony Plus and most countertop dispensers manufactured by Cornelius •...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Docking assembly Ice transport tube External connection Internal connection Front cover HARMONY and Symphony Plus • RIDE Technology remote...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack carton #1 ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ HARMONY and Symphony Plus • RIDE Technology...
-
Page 5: Site Preparation
• 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable federal, state, and local codes Drains: ➌... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Attention! The location of the hole in the dispenser top is dependent on the type of dispenser. Be sure to follow Step 3.1 for the appropriate dispenser. Hole location - Harmony (Lancer, Cornelius or Servend), or 110CM Symphony Plus Lancer Sensation and Touchpoint Standard (Cornelius, Lancer, or Servend) 110CM Symphony Plus... - Page 7 Top preparation Top preparation — – ˜ – • Remove protective tape from gaskets • Apply gaskets ➊ • Install shuttle actuator ➋ through dispenser top and secure with locking nut ➌ Top preparation Agitation adjust. – CORNELIUS — – Cornelius models ED, DB, DF, IDC and FLAVOR FUSION •...
- Page 8 Agitation adjustments – LANCER 4500 SERIES ROCKER PRESS IN ON PRESS IN ON AGITATION TIME SWITCHES THIS SIDE TO THIS SIDE TO (VIEW LOOKING TURN SWITCH TURN SWITCH DOWN) OFF. SWITCH X = ON NUMBER O = OFF AGITATION FREQUENCY SWITCH SWITCH NUMBER...
- Page 9 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 – Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Enter...
- Page 10 3.10 Dispenser diverter plate overview (Installation on next page) Single Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) Dual Agitator P/N 307277 — Diverter plate (single agitator Cornelius dispensers and left-hand dispense chute on dual-agitator Cornelius dispensers) P/N 00996207 —...
- Page 11 3.11 Dispenser diverter plate installation – CORNELIUS ED, DF and DB SERIES GATE MOUNTING PLATE STORAGE HOPPER FLANGE EXTENDS INTO STORAGE HOPPER THROUGH GATE OPENING ICE DIVERTER ICE CHUTE COVER APPLY RTV TO THIS SURFACE TO SEAL TO HOPPER GATE MOUNTING PLATE 10-32 WASHER GASKET...
-
Page 12: Before Proceeding
Docking assembly Install the docking assembly. BEFORE PROCEEDING Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. -
Page 13: Docking Station
Undercounter installation requirements Top View ➌ ➊ 3.25" (83 mm) min. Access panel/ door on counter 23.5" min. (59.7 mm) 24" min. (61 mm No Lip ➋ DOCKING STATION • Prior to installing the docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. - Page 14 Transport tube Install the transport tube. Transport tube installation. ➋ Hot Water ➍ 160 F (71 C) ➎ ➏ ➐ ➑ ➒ ➓ ➊ ➌ 1/4" Ice transport tube tips • Insulate entire length of ice transport tube ➊ • Secure ice transport tube ➋...
-
Page 15: External Connections
External connections Connect utilities to docking assembly. Water and drain Chassis drain plumbing - required ➊ ➋ ➌ Minimum 8" ➏ radius • Plug must be removed from John Guest 2 ft. x 1" OD fitting. silicone tubing • Route 3/8" drain tubing through knockout in back of docking station and insert fully into John Guest fitting connection at the 3/4"... -
Page 16: Internal Connections
Internal connections Connect docking assembly to ice machine. Ice transport tube installation Water line ➋ ➊ ➌ Mount water ➋ solenoid ➊ • Slide ice machine into docking assembly • Mount water solenoid to inside rear of ensuring that drain tube is fully seated on docking assembly using one screw ➊... - Page 17 TDS switch Power cord HIGH CLEAN • Set the TDS switch on the electrical box: • Position plate into opening and secure with supplied screw HIGH: for extended service life LOW: for low-scale water HARMONY and Symphony Plus • RIDE Technology remote...
-
Page 18: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of docking • Complete installation of condensing unit assembly ➊... - Page 19 Long tube run recommendations max. 2 ft (.6m) ➊ ➋ 1/4" ➊ • Pitch ice transport tube to allow melt water to drain towards ice machine ➋ • Secure insulated ice transport tube at least every 2 ft (.6m) to prevent dips or traps HARMONY and Symphony Plus •...
- Page 20 Horizon, Horizon Elite, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett Follett LLC. Chewblet, RIDE and Follett are registered trademarks of Follett Follett LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
