ASSEMBLY INSTRUCTIONS
STEP 2
1. Slide two Rubber Rings (43) onto two Weight Guide Tubes (5).
2. Slide nine Weight Plates (39) down two Weight Guide Tubes (5).
3. Slide the Selector Shaft Bushing (52) down the Selector Shaft (22) at First hole fix with the
Selector Shaft Pin (53).
4. Insert the Selector Shaft (22) into hole of the Weight Plate (39).
5. Slide the Top Weight Plate (38) down the Selector Shaft (22). Insert the Weight Selector Pin
(51) into hole of desired Weight.
6. Put the Plastic Washer (54) on the Top Weight Plate (38).
