- Page 1 Manual Quattro (with firmware xxxx400 or higher) 48|3000|35-50|50 120V...
-
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS In general Please read the documentation supplied with this product first, so that you are familiar with the safety signs en directions before using the product. This product is designed and tested in accordance with international standards. The equipment should be used for the designated application only. - Page 4 2. DESCRIPTION 2.1 In general The basis of the Quattro is an extremely powerful sine inverter, battery charger and automatic switch in a compact casing. The Quattro features the following additional, often unique, characteristics: Two AC inputs; integrated switch-over system between shore voltage and generating set The Quattro features two AC inputs (AC-in-1 and AC-in-2) for connecting two independent voltage sources.
-
Page 5: Battery Charger
Solar energy The Quattro is extremely suitable for solar energy applications. It can be used for building autonomous systems as well as mains-coupled systems. Emergency power or autonomous operation on mains failure Houses or buildings provided with solar panels or a combined micro-scale heating and power plant (a power-generating central heating boiler) or other sustainable energy sources have a potential autonomous energy supply which can be used for powering essential equipment (central heating pumps, refrigerators, deep freeze units, Internet connections, etc.) during a power failure. -
Page 6: Operation
3. OPERATION 3.1 “On / stand by / charger only” switch When switched to "on", the product is fully functional. The inverter will come into operation and the LED "inverter on" will light An AC voltage connected to the "AC in" terminal will be switched through to the "AC out" terminal, if within specifications. The inverter will switch off, the "mains on"... - Page 7 3.4 LED indications and their meaning LED off LED flashes LED lights Inverter Charger inverter mains on inverter on Bulk overload The inverter is on, and supplies power to the load. absorption low battery charger Float only temperature Charger inverter mains on inverter on The nominal power of the inverter is...
- Page 8 charger inverter mains on inverter on The inverter is switched off due to bulk overload excessively high internal temperature. absorption low battery charger float only temperature charger inverter mains on inverter on – If the LEDs flash alternately, the battery almost empty and nominal bulk overload power is exceeded.
- Page 9 Battery charger charger inverter mains on inverter on The AC voltage on AC-in-1 or bulk overload AC-in-2 is switched through, and the charger operates in bulk phase. absorption low battery charger only float temperature charger inverter mains on inverter on The AC voltage on AC-in-1 or AC-in-2 is switched through and the bulk...
-
Page 10: Special Indications
Special indications Set with limited input current charger inverter mains on inverter on The AC voltage on AC1-in-1 or AC-in-2 is switched through. The bulk overload AC-input current is equal to the load current. The charger is down- absorption low battery controlled to 0A. -
Page 11: Installation
4. INSTALLATION This product may only be installed by a qualified electrical engineer. 4.1 Location The Quattro should be installed in a dry, well-ventilated location, as close as possible to the batteries. The device should be surrounded by a free space of at least 10 cm for cooling purposes. An excessively high environmental temperature has the following consequences: - shorter lifespan... - Page 12 4.3 Connecting AC cables The Quattro is a safety class I product (supplied with an ground terminal for safety purposes). Its AC input and/or output terminals and/or grounding point on the outside of the product must be provided with an uninterruptable grounding point for safety purposes.
-
Page 13: Connection Options
4.4 Connection options 4.4.1 Starter battery (connection terminal G, see appendix A) The Quattro has a connection for charging a starter battery. Output current is limited to 4A. 4.4.2 Voltage sense (connection terminal E, see appendix A) For compensating possible cable losses during charging, two sense wires can be connected with which the voltage directly on the battery or on the positive and negative distribution points can be measured. - Page 14 5. CONFIGURATION - Settings may only be changed by a qualified electrical engineer. - Read the instructions thoroughly before implementing changes. - During setting of the charger, the DC fuse in the battery connections must be removed. 5.1 Standard settings: ready for use On delivery, the Quattro is set to standard factory values.
- Page 15 Inverter voltage Output voltage of the Quattro in battery operation. Adjustability:110 – 130V Stand-alone / parallel operation / 2-3 phase setting Using several devices, it is possible to: - increase total inverter power (several devices in parallel) - create a split-phase system (only for Quattro units with 120V output voltage) - create a 3-phase system.
- Page 16 Note: when WeakAC is on, the maximum charge current is reduced by approximately 20%. Not adjustable with DIP switches. BoostFactor Change this setting only after consulting with Victron Energy or with an engineer trained by Victron Energy! Not adjustable with DIP switches. Auxiliary AC output (AC-out-2) Besides the uninterruptable output (AC-out-1), a second output (AC-out-2) is available that disconnects its load in the event of battery operation.
- Page 17 5.3 Configuration by computer All settings can be changed by means of a computer or with a VE.Net panel (except for the multi-functional relay and the VirtualSwitch when using VE.Net). The most common settings (including parallel and 3-phase operation) can be changed by means of DIP switches (see Section 5.5).
- Page 18 5.5 Configuration with DIP switches Introduction A number of settings can be changed using DIP switches (see appendix A, position M). Note: When changing settings with dipswitches in a parallel or split-phase/3-phase system one should be aware that not all settings are relevant on all Quattros.
- Page 19 Procedure AC-in-1 can be set using DIP switches ds8, ds7 and ds6 (default setting: 50A). Procedure: set the DIP switches to the required value: ds8 ds7 ds6 off = 6A (0,72kVA at 120V) on = 10A (1.2kVA at 120V) off = 12A (1.4kVA at 120V) on = 16A (2kVA at 120V) off = 20A (2.4kVA at 120V) on = 25A (3kVA at 120V)
- Page 20 5.5.1.4 Examples examples of settings: DS-8 AC-in-1 DS-8 DS-8 DS-8 DS-7 AC-in-1 DS-7 DS-7 DS-7 DS-6 AC-in-1 DS-6 DS-6 DS-6 DS-5 AC-in-2 DS-5 DS-5 DS-5 DS-4 Charging current DS-4 DS-4 DS-4 DS-3 DS-3 DS-3 DS-3 Charging current DS-2 DS-2 DS-2 DS-2 Stand-alone mode DS-1 DS-1...
- Page 21 Step 2: Exemplary settings Example 1 is the factory setting (since factory settings are entered by computer, all DIP switches of a new product are set to ‘off’ and do not reflect the actual settings in the microprocessor). DS-8 Ch. voltage DS-8 DS-8 DS-8...
-
Page 22: Maintenance
6. MAINTENANCE The Quattro does not require specific maintenance. It will suffice to check all connections once a year. Avoid moisture and oil/soot/vapours, and keep the device clean. 7. ERROR INDICATIONS Important note: When the battery is completely discharged (battery voltage less than 10V / 20V or 40V), the Quattro will start charging only when AC power is connected to AC-in-1. - Page 23 The absorption time is too short. For adaptive Reduce the charging current or select the ‘fixed’ charging this can be caused by an extremely high charging characteristics. charging current with respect to battery capacity, so that bulk time is insufficient. The battery is overcharged.
- Page 24 4) Update the firmware in the last device that was switched on. Should not occur. Switch all equipment off, and then on again. Contact Internal error. Victron Energy if the problem persists.
-
Page 25: Technical Specifications
8. TECHNICAL SPECIFICATIONS Quattro 48/3000/35-50/50 120V PowerControl / PowerAssist Integrated Transfer switch AC inputs (2x) Input voltage range: 95-130 VAC Input frequency: 45 – 65 Hz Power factor: 1 Maximum feed through current (A) AC-in-1: 50A AC-in-2: 50A Minimum PowerAssist current (A) AC-in-1: 7,5A AC-in-2: 7,5A INVERTER... -
Page 27: Appendix A: Connection Overview
APPENDIX A: Connection overview... - Page 28 APPENDIX A: Connection overview A AC input (generator input) AC-in-1. Left to right: GROUND (earth), L (phase), N (neutral). B 2x RJ45 connector for remote panel and/or parallel and 3-phase operation. C AC output AC-out-1. Left to right: L (phase), N (neutral), GROUND (earth). D AC output AC-out-2.
-
Page 29: Appendix B: Block Diagram
APPENDIX B: Block diagram * See table in Chapter 4.2 “Recommended DC fuse”. -
Page 30: Appendix C: Parallel Connection
APPENDIX C: Parallel connection... -
Page 31: Appendix D: Three-Phase Connection
APPENDIX D: Three-phase connection... -
Page 32: Appendix E: Charge Characteristics
APPENDIX E: Charge characteristics Charge current 120% 100% Amps Time Volts Charge voltage Time 4-stage charging: Bulk Entered when charger is started. Constant current is applied until nominal battery voltage is reached, depending on temperature and input voltage, after which constant power is applied up to the point where excessive gassing is starting (14.4V resp. 28.8V, temperature- compensated). -
Page 33: Appendix F: Temperature Compensation
APPENDIX F: Temperature compensation Default output voltages for Float and Absorption are at 25°C. Reduced Float voltage follows Float voltage and Raised Absorption voltage follows Absorption voltage. In adjust mode temperature compensation does not apply. -
Page 34: Appendix G: Dimensions
APPENDIX G: Dimensions... - Page 36 Serial number: Version : 13 Date : July 10 , 2020 Victron Energy B.V. De Paal 35 | 1351 JG Almere PO Box 50016 | 1305 AA Almere | The Netherlands General phone +31 (0)36 535 97 00 E-mail sales@victronenergy.com...
