- Page 1 Manual Handleiding Manuel Anleitung Manual Användarhandbok Phoenix Inverter Smart 12 | 1600 230V 12 | 2000 230V 12 | 3000 230V 24 | 1600 230V 24 | 2000 230V 24 | 3000 230V 48 | 1600 230V 48 | 2000 230V 48 | 3000 230V...
-
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS General Please familiarize yourself with the safety features and instructions by first reading the documentation supplied with this product before using the equipment. This product has been designed and tested in accordance with international standards. The equipment must be used exclusively for the purpose for which it was designed. -
Page 4: Transport And Storage
Transport and Storage Ensure that the mains power and battery leads have been disconnected before storing or transporting the product. No liability can be accepted for any transport damage if the equipment is shipped in non- original packaging. Store the product in a dry environment; the storage temperature must be between -20°C and 60°C. - Page 5 2. DESCRIPTION 2.1 General Bluetooth built-in: fully configurable with a tablet or smartphone Low battery voltage alarm trip and reset levels • Low battery voltage cut-off and restart levels • Dynamic cut-off: load dependent cut-off level • Output voltage: 210 - 245V •...
-
Page 6: Operation
3. OPERATION 3.1 On/Off Switch When switched to "on" with the push button, the product is fully functional. The inverter will come into operation and the LED "inverter" will light up. By pushing the push button subsequently, within a short period of time, the inverter toggles between “on”, “ECO” and “off”. Apart from the pushbutton;... - Page 7 blink frirmware Firmware update in progress or firmware update failed. update in When failed; retry firmware update. progress or failed Yellow LED Status Trouble shooting ●●●●●●●● Red LED Off Solid on ECO mode status OK Red LED On or blinking: The Inverter is still on, but will shut down when the condition gets worse.
- Page 8 After three restarts followed by a low battery shutdown within 30 seconds of restarting, the inverter will shutdown and stop retrying. The LEDs will signal low battery shutdown. To restart the inverter, switch it Off, and then On, or recharge the battery: as soon as the battery has risen and then stays above the Charge detect level for 30 seconds, it will switch on.
-
Page 9: Installation
4. INSTALLATION This product should be installed by a qualified electrician. During installation ensure that the remote connector with wire bridge is removed (or swtich off the remote on/off switch if installed) to be sure that the inverter cannot be switched on unexpectedly. 4.1 Location The product must be installed in a dry and well-ventilated area, as close as possible to the batteries. -
Page 10: Connection Of Battery Cables
4.2 Connection of Battery cables In order to fully utilize the full capacity of the product, batteries with sufficient capacity and battery cables with sufficient cross section should be used. See table. 12/1600 24/1600 48/1600 12/2000 24/2000 48/2000 Recommended cross section (mm length up to 6 m 12/3000 24/3000... - Page 11 4.3 DC safety fuse There is no safety fuse inside the inverter; this should be installed externally. The recommended safety fuses can be found in the table below 12/1600 24/1600 48/1600 12/2000 24/2000 48/2000 Recommended 250A 125A 300A 150A DC fuse 12/3000 24/3000 48/3000...
-
Page 12: Optional Connections
4.4 Connection of the AC cabling This is a Safety Class I product (supplied with a protective grounding terminal). The neutral wire of the AC output of this inverter is connected to the chassis (see appendix B for 1600VA/2000VA and appendix C for 3000VA). - Page 13 Relay on during normal operation. The relay will switch off once there is a low battery warning. It will remain off in case the inverter shuts down due to low voltage, and will only switch back on again once the inverter is operational and the battery voltage is above the pre-alarm reset level.
- Page 14 5. CONFIGURATION Settings may only be changed by a qualified engineer. Carefully read the instructions before changes are made. Batteries should be placed in a dry and well-ventilated area during charging. 5.1 Standard settings: ready for use On delivery, the Phoenix inverter is set to standard factory values. In general, these settings are suitable for stand-alone operation.
-
Page 15: Configuration By Computer
Dynamic Cut-off Use VictronConnect to enable and configure Dynamic Cut-off (see https://www.victronenergy.com/live/ve.direct:phoenix-inverters-dynamic-cutoff for details). Do not use Dynamic Cut-off in an installation that also has other loads connected to the same battery: the battery voltage will drop because of the extra load, but the Dynamic Cut-off algorithm in the Inverter is not aware of that load: hence the Inverter will shut down too early with an under voltage alarm. -
Page 16: Technical Data
7. Technical data 12 Volt 12/1600 12/2000 12/3000 Phoenix Inverter Smart 24 Volt 24/1600 24/2000 24/3000 48 Volt 48/1600 48/2000 48/3000 Parallel and 3-phase operation INVERTER Input voltage range (1) 9,3 – 17V 18,6 – 34V 37,2 – 68V Output Output voltage: 230VAC ±2% 50 Hz or 60Hz ±... -
Page 17: Appendix A: Inverter Control
Appendix A: Inverter control Bijlage A: Besturing van de omvormer Annexe A : Contrôle du convertisseur Anhang A: Wechselrichtersteuerung Apéndice A: Control del inversor Bilaga A: Växelriktarkontroll... -
Page 18: Appendix B: Installation Information 1600Va/2000Va
www.victronenergy.com Appendix B: Installation information 1600VA/2000VA This ground wire “G“ connects the output neutral to ground. It must be repositioned to a ‘dummy’ terminal if a floating output is required. When a floating output is obtained the current reading at no load can show an offset of around 100…150mA. - Page 19 Apéndice B: Instrucciones de instalación Este cable de puesta a tierra “G“ conecta la salida neutra a tierra. Debe reposicionarse en una conexión ficticia si se necesita una salida flotante. Cuando se obtiene una salida flotante, la lectura de corriente sin carga puede mostrar una descompensación de entorno a 100…150 mA.
-
Page 20: Appendix C: Installation Information 3000Va
www.victronenergy.com Appendix C: Installation information 3000VA This ground wire “G“ connects the output neutral to ground. It must be repositioned to a ‘dummy’ terminal if a floating output is required. When a floating output is obtained the current reading at no load can show an offset of around 100…150mA. - Page 21 Wenn der „Floating“ Ausgang eingerichtet ist, kann es beim ermittelten Stromwert ohne angeschlossene Lasten eine Verschiebung von ca. 100...150 mA geben. Bedenken Sie außerdem, dass der FI-Schutzschalter (bzw. der Fehlerstromschutzschalter) nicht ordnungsgemäß funktionieren wird. Apéndice C: Instrucciones de instalación Este cable de puesta a tierra “G“ conecta la salida neutra a tierra. Debe reposicionarse en una conexión ficticia si se necesita una salida flotante.
- Page 22 Serial number: Version : 01 Date : March 4 , 2020 Victron Energy B.V. De Paal 35 | 1351 JG Almere PO Box 50016 | 1305 AA Almere | The Netherlands General phone : +31 (0)36 535 97 00 E-mail : sales@victronenergy.com...
