Draper TK58/BL User Information

USER
INFORMATION
Stock No. 28106/28111
Read this manual in full before attempting
to use this product and retain it for future
use. Always use the latest version of
the manual.
1. Voltage Tester
1.1 Scope
This product is designed to test the
voltage at a given point in a circuit and
to locate breakages in cables. Any other
application is considered misuse. Draper
Tools accepts no responsibility for
improper use of this product.
Voltage testing range: 12–250V AC/DC
1.2 Safety Information
WARNING! Working with electricity is
dangerous. Always consult a suitably
qualified person if you are not certain
of what you are doing. NEVER touch
the metal blade during use.
Important: This product is NOT
a screwdriver. Using it as such is
dangerous and may cause damage to
the user or tool.
Part No. TK58/BL
TK58/GR
1.3 Operating Instructions
Voltage Test
Place the blade into or onto a "live"
aperture or contact and press and
hold the "Direct Test" button. An
approximation of the voltage is
indicated on the LCD display.
Induction Test
To find a broken cable, ensure that
the supply is live, press and hold the
"Induction Break-Point Test" button and
track the blade from the plug towards
the appliance. A lightning symbol is
shown on the LCD display until a break
is detected. Repeat the test to confirm
the location.
1.4 Disposal
Dispose of this tool in accordance with
local regulations.
• DO NOT dispose of this tool with
domestic waste.
• DO NOT dispose of this tool in
unsorted municipal waste.
• DO NOT incinerate.
• DO NOT abandon in the environment.
EN
Original Instructions
Version 1 – May 2022
