DigiMod 2000HV
The DigiMod 2000HV is a power amplifier module specifically
designed for 2-channel applications where high output voltage level
is required, and with its 2x1050W on 8� and 1x2100W in bridged
mode is the perfect engine to drive rock solid double subwoofers
or high power 2-way systems.
Specifically designed DSP boards with advanced processing, remote control
and networking capabilities are available for DigiMod 2000HV, to
perfectly fit with the amplifier and providing a complete solution in
a compact package.
Specifications
AC Mains Power
Operating voltage
Efficiency
Power consumption
I/8 of max power @ 8 � bridged
Max aux supply current draw
Construction
Dimensions
Weight
Technical Support
Should you encounter any difficulties in operating this amplifier
module, please do not hesitate to contact our technical support.
We will be glad to be of assistance.
support@powersoft.it
Powersoft
Via Enrico Conti, 13/15
50018 Scandicci - Firenze
Italy
Tel/fax: +39 055 735 1386
AC 195V – 250V @ 50/60Hz,
I = 2.9 A
*
nom RMS
AC 95V – 125V @ 50/60Hz,
I * = 5.5 A
nom RMS
*
1/8 max output power
> 80% (typical )
410 VA
200 mA
216 mm x 122 mm x 69 mm
(8.5" x 4.8" x 2.7")
1.15 kg (2.5 lb)
Via Enrico Conti, 5
50018 Scandicci (FI)
www.powersoft-audio.com
®
