EDGE Installation Manual

Ford Crown Victoria Monitor Installation

1. Use four (4) provided 10-32 X
head screws to secure the monitor mount to the
back of the EDGE monitor.
2. Align Monitor Mount between the two visors;
secure the mount with four (4) provided #10-16
x 1 ¼" self tapping screws.
3. To ensure a solid mount, make sure the monitor
mount is screwed onto the support beam.
4. Secure and zip ties the cable to the mount.
Please ensure there are enough slack on the
cable to allow rotation of the monitor. Ensure
there are enough slack on the cable to allow
monitor rotation.
Note: The monitor mount provides three possible
mounting positions on the camera mount, forward,
middle, and back. Choose the position that best fits
the needs of the vehicle and user when installing.
3
/ " Phillips pan
8
