Additional And Advanced Operations - CODELOCKS CL4500 Getting Started

#Master Code • 01 • New Master Code • New Master Code • •
Example: #12345678 • 01 • 87654321 • 87654321 • •
Result: The Master Code has been changed to 87654321.
Note: The Master Code is 8 digits in length
Set or Change the Sub-Master Code
#Master Code • 02 • New Sub-Master Code • New Sub-Master Code • •
Example: #12345678 • 02 • 44556677 • 445566677 • •
Result: The Sub-Master Code has been changed to 44556677.
Note: The Sub-Master Code is 8 digits in length
Clients (Users)
Add a User Code Client
#Master Code • 20 • 1 • User Code ••
Example: #12345678 • 20 • 1 • 3366 ••
Result: The User Code 3366 can now be used to unlock the lock.
Other Programs Available: Create one-time User Code Clients, Suspend User Code Clients and Restore User Code Clients. Please refer to the
Programming & Operating Instructions.
Add a Smart Card Client
#Master Code • 20 • 3 •• present MIFARE
Example: #12345678 • 20 • 3 •• present MIFARE
Result: The smart card will be able to unlock the lock.
Delete a Client
#(Sub)Master Code • 25 • <User Code|Present Smart Card> ••
Example: #11335577 • 25 • 1199 ••
Result: The User Code 1199 has been deleted.

Additional and Advanced Operations

For the full range of available programs, please refer to the Programming & Operating Instructions.
Active Periods
Each Client, when set up via the Codelocks Connect App can have up to 10 Active Periods which can limit their access to set weekdays and
times.
Code Free
Automatic and manual Code-Free options allow free passage to be enabled on a timed schedule or by an authorised Client. Automatic Code-
Free can be enabled via the App or keypad.
Do-Not-Disturb
Provides an additional level of privacy by temporarily blocking access to other Clients. Do-Not-Disturb can be configured via the App.
Dual Authorisation
Where an additional level of access control is required, the lock can be configured to require two valid credentials before unlocking. Dual
Authorisation can be configured via the App or keypad.
GuestLock
Providing a simple way for guests to choose their own door code when checking into their room. GuestLock can be configured via the App or
Keypad.
Lockdown
Lockdown prevents all access to all Clients except the Master Code and can be triggered by the Master Code, Sub-Master Code, any Client with
the lockdown setting enabled or via a button connected to REM 2.
®
