Intex PureSpa SB-HSWF10 Owner's Manual page 6

Before assembling your product, please take a few minutes to check the contents
REF.
DESCRIPTION
NO.
1 CONTROL BASE
2 SIDE COVER HINGE BASE
3 SIDE COVER HINGE FIXER
4 CONTROL BASE SIDE COVER
5 CONTROL PANEL
6 ELECTROLYTIC CELL COVER
7 SPA/COVER INFLATION HOSE
8 SPA CONTROL INLET/OUTLET O-RING
9 SPA CONTROL AIR INLET O-RING
10 SPA DRAIN PLUG
11 SUCTION FITTING
12 FILTER CARTRIDGE HOUSING
13 FILTER CARTRIDGE
14 FILTER CARTRIDGE HOUSING LID
15 INLET/OUTLET PLUG
16 SPA TUB
17 ENERGY SAVING SPA COVER
18 SPA INFLATABLE BLADDER
19 GROUND CLOTH
20 SPA FILTER MOTOR
21 TEST STRIPS
22 WRENCH
23 AIR PRESSURE RELEASE VALVE CORE
24 ELECTROLYTIC CELL O-RING
25 MALE BUCKLE
26 FEMALE BUCKLE
27 ELECTROLYTIC CELL
28 ELECTROLYTIC CELL COVER O-RING
When ordering parts, be sure to quote the model number and part numbers.
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 8.5 gpm (510 gph)
• Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
• For service and winterization instructions refer to "Maintenance" and "Storage" sections.
• Read and follow all instructions, save these instructions for future reference.
S AVE THESE INSTRUCTIONS
PARTS (continued)
and become familiar with all the parts.
SPA SUCTION FITTING
(353PO) SPA ENGLISH 7.5" X 10.3" PANTONE 295U 02/03/2023
PART NO.
QTY. 4 ADULTS
28449EP 28445EP
1 13101 13101C
2 12771 12771D
2 12772 12772D
2 12770 12770W
1 13100 13100C
1 13116 13116C
1 13098 13098
2 11699 11699
1 11788 11788
1 13076 13076
2 11695 11695
2 11798 11798
2 11692 11692
2 11797 11797
3 11739 11739
1 13103 13103C
1 13148G 13148
1 13149 13149
1 13111 13111
1 12777 12777
1 11855 11855
1 11742A 11742A
1 12589A 12589A
2 13099 13099
1 11994 11698
9 11993 11799
1 13113 13113
1 13115 13115
353
English
PO
6 ADULTS
28451EP 28471EP
13101 13101C
12771 12771D
12772 12772D
12770 12770W
13100 13100C
13116 13116C
13098 13098
11699 11699
11788 11788
13076 13076
11695 11695
11798 11798
11692 11692
11797 11797
11739 11739
13105 13105C
13150G 13150C
13151 13151
13112 13112
12777 12777
11855 11855
11742A 11742A
12589A 12589A
13099 13099
11994 11698
11993 11799
13113 13113
13115 13115
Page 6
