SimpleSpa™
SB-B20
For illustrative purposes only.
Do not forget to try these other fine Intex products: pools, pool
accessories, in-home toys, airbeds and boats available at fine
retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual without notice.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong
Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué
dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading
B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
(348IO) SPA ENGLISH 7.5" X 10.3" PANTONE 295U 10/09/2019
IMPORTANT
SAFETY RULES
Please read, understand, and follow all
instructions carefully before installing
and using this product. Keep for future
©2019 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/
Gedruckt in China.
English
reference.
348-*A*-R0-2011
348
A
Advertisement
Table of Contents
Related Manuals for Intex SimpleSpa SB-B20
Summary of Contents for Intex SimpleSpa SB-B20
- Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...
-
Page 2: Table Of Contents
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English TABLE OF CONTENTS Warning..................3-6 Parts....................Set-up..................... 9-14 Operation..................LED Code Chart................16 Minimize Heat Loss and Energy Consumption Advice..... 17 Maintenance and Chemicals............18-22 Storage................... 22 Troubleshooting................23-24 Filter pump motor disassembly........... 25 Warranty.................. -
Page 3: Warning
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English IMPORTANT SAFETY RULES When installing and using this electrical equipment, basic safety precautions should always be followed, including the following. READ AND FOLLOW ALL INSTRUCTIONS DANGER • Risk of Accidental Drowning (especially children under 5 years). Caution shall be exercised to prevent unauthorized access to spa by children. - Page 4 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English WARNING c) The user should check the water temperature before entering the spa. d) The use of alcohol, drugs, or medication before or during spa use may lead to unconsciousness with the possibility of drowning.
- Page 5 • Do not allow the water in the spa to freeze. Do not turn on the spa when the water is frozen. • Do not use the spa if damaged in delivery and/or malfunctioning in any fashion. Contact the Intex service center for further direction.
- Page 6 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English WARNING • Barriers, covers, alarms, or similar safety devices are helpful aids, but they are not substitutes for continuous and competent adult supervision. Safety equipment • Keep a working phone and a list of emergency phone numbers near the spa. Safe use of the spa •...
-
Page 7: Parts
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English PARTS Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. S AVE THESE INSTRUCTIONS Page 7... - Page 8 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English PARTS (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. REF. NO. DESCRIPTION QTY. PART NO. CONTROL BASE 12838 SIDE COVER HINGE BASE 12771...
-
Page 9: Set-Up
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English PRODUCT SPECIFICATIONS Voltage / Frequency / Phase 220 - 240 V / 50 Hz / 1 PH Maximum seating capacity: 4 adults Water capacity: 210 gal (795 L) Inner/outer diameter: 57/77 in (145/196 cm) Height: 26 in (66 cm) - Page 10 Lay out all the parts on the ground and make sure all the parts are accounted for. For missing or damaged parts contact the appropriate Intex Service Center listed in the separate “Authorized service Centers” sheet. Spa Control Panel Adjustment 1. Push the lever down to tilt up the control panel and flip up the panel cover (see drawing 1.1).
- Page 11 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SET UP (continued) Optional equipotential bonding system Depending on local building codes and regulations, have a qualified electrician to connect the spa equipotential terminal with a conductor (wire) having a nominal cross-sectional area of 2.5 mm to 6mm the household equipotential terminal. (Wire not included) Inflation Inflate the Spa Tub Wall Take out the ground cloth (19) and spread it over the cleared area.
- Page 12 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SET UP (continued) Press the button to turn on the control panel. Press the button to inflate the spa tub wall for 8 to 10 minutes until it is firm to the touch but not hard (see drawings 4.1 & 4.2). During the inflation process check that the spa tub external lining (31) top surface is fully extended and covering the spa tub (16) top air chamber surface, make adjustment as needed. After inflation a few wrinkles may be present on the spa tub external lining, this is normal.
- Page 13 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SET UP (continued) Inflate the Spa Cover Air Bladder Open the inflation valve and insert the inflation hose (7) into the valve; press to inflate until it is firm to the touch but not hard (see drawing 7). Disconnect the inflation hose (7) from the air blower inflation outlet and the valve. Replace the control base inflation latch back; close and recess the inflation valve. NOTE: If there is a need to add some air to the spa tub wall or spa cover air bladder after they have been setup, refer to above “Inflate the Spa Tub Wall” and “Inflate the Spa Cover Air Bladder” sections.
- Page 14 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SET UP (continued) Spa Control Unit Installation Connect the spa control unit to the spa tub (see drawing 9). Hand-tighten the connectors securely. Do not use tools to tighten. NOTE: Never attach external accessories not supplied with the kit to the spa tub or control base unit, as this will void the warranty.
-
Page 15: Operation
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English OPERATION SPA CONTROL UNIT PANEL A: Heat Button B: Celsius/Fahrenheit Toggle Button C: Temperature Increase Button D: Temperature Decrease Button E: Water Filter Button F: Bubble Button G: LED Display H: On/Off Button On/Off Button: Once the unit is plugged in, use this button to active the control unit panel... -
Page 16: Led Code Chart
• If problem persists, contact Intex Service Center. Dry-fire Protection • Contact Intex Service Center. Water temperature sensor broken • Contact Intex Service Center. After 72 hours of continuous heating operation, the pump will • Press the button to re-active the hibernate automatically. -
Page 17: Minimize Heat Loss And Energy Consumption Advice
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English MINIMIZE HEAT LOSS AND ENERGY CONSUMPTION ADVICE 1) Always keep the spa cover on to minimize heat loss during heating of the spa between uses (but not while it is being used). Ensure the cover is fitted tightly, as per manufacturer’s instructions to maximize insulation. It shall be recommended that the cover, when not in use, should be kept off the ground to retain its cleanliness (particularly the surface in close proximity to the water spa water surface). -
Page 18: Maintenance And Chemicals
Do not add chemicals if the spa is occupied. This can cause skin or eye irritation. Concentrated chlorine solutions can damage the spa tub. In no event is Intex Recreation Corp., Intex Development Co. Ltd., their related companies, authorized agents and service centers, retailers or employees liable to the buyer or any other party for costs associated with the loss of spa water, chemicals or water damage. - Page 19 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SPA WATER CHEMISTRY AND BALANCE Parameter Value Water clarity clear view of the bottom Total Alkalinity (TA) in mg/l 60 to 120 Calcium Hardness (CaCO ) in mg/l 150 to 250 b, c Colour of the water no colour should be observed...
- Page 20 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English SPA WATER CHEMISTRY AND BALANCE (continued) Calcium Hardness (CaCO ): refers to the amount of calcium and magnesium dissolved in the water. Result if too low – Difficulty balancing water, corrosion of metal components, eye & skin irritation and water foaming. Result if too high – Scale formation, cloudy water, eye & skin irritation, difficulty balancing water and filter/ heater inefficiency. Saturation Index (SI): temperature, calcium hardness concentration, total alkalinity and pH represent the main factors influencing scale formation. The tendency of water to either form scale or corrode is indicated by the Saturation Index (SI): SI = pH+TF+CF+AF-12.1...
- Page 21 (348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English MAINTENANCE Spa Tub Drainage Turn off the spa control unit. Connect the drain valve adaptor to a garden hose and point the other end of the garden hose to a suitable draining area (see drawing 13). Remove the drain valve cap from outside of the spa tub and attach the drain valve adaptor to the drain valve (see drawing 13).
-
Page 22: Storage
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English MAINTENANCE (continued) Spa Surround Barefoot areas and relaxing areas around the spa shall be cleaned on a regular basis. No cleaning water may flow into the spa or spa water cycle. The dirt and cleaning agents shall be rinsed carefully to drain in the spa surround. Spa Tub and Cover Air Bladder Repair Use the enclosed repair patch to repair any puncture: •... -
Page 23: Troubleshooting
• Air blower pump is too hot. • Turn off and unplug the spa. Let it cool down and BLOWER DOES restart all over again. NOT WORK • If problem persists, contact Intex Service Center. FILTRATION PUMP • Dirty filter cartridge. • Clean or replace the filter cartridge in time. NOT WORKING •... - Page 24 IS WEAK DURING • Inflation hose adaptor not securely • Tighten/reinstall hose adaptor. INFLATION tighten. • Finger tighten during inflation. • Connection between the hose • If problem persists, contact Intex Service Center. adaptor and blower inflation outlet, and between the inflation hose and inflation valve are loose. • Air blower failure. AIR BUBBLES ARE • O-ring missing between the control •...
-
Page 25: Filter Pump Motor Disassembly
(348IO) SPA ENGLISH 7.5” X 10.3” PANTONE 295U 10/09/2019 English FILTER PUMP MOTOR DISASSEMBLY If there is a need to replace the filter motor (for qualified technician only), follow below steps to disassemble it: IMPORTANT: You must drain out any remaining water inside the piping system of the control base before replacing any parts. Tools required: One adjustable wrench and one Philip screwdriver. NOTE: The “special wrench tool” is included with the new filter pump motor replacement and not with the spa set. -
Page 26: Warranty
Other than this warranty, and other legal rights in your country, no further warranties are implied. To the extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or consequential damages arising out of the use of your SimpleSpa, or Intex or its agents’ and employees’...
