Perle IDS-710HP Quick Start Manual

___________________________________________________
This guide covers basic installation and configuration and is intended for first
time setup or product evaluation.
Complete details can be found in the following guides at
www.perle.com/downloads.

IDS-710HP (-XT) Hardware Installation Guide
 IDS Managed PoE+ Switches User Guide - PRO Feature Set
 IDS Managed PoE+ Switches CLI Reference Guide - PRO Feature Set
What's in the box?

The IDS switch

Quick Start Guide (this document)
Hardware Overview
Front View
IDS-710HP Switches Quick Start Guide P/N: 5500457-10 Version #01.02.2020
Back View
1 – Reset/FS (Fast Setup)
2 – Status LEDs
3 – Digital Inputs/Relay I/O
4 – SFP status LEDs
5 – Console port – Micro USB
6 – SFP slots
7 – 10/100/1000Base-T, PoE
capable, Ethernet ports
8 – Terminal block for power 1
and 2
9 – Wall mount bracket screw
holes
10- DIN rail clip
11- Ethernet port LED1
12- Ethernet port LED2
IDS-710HP
Quick Start Guide
