Saxby Lighting 75434 Instruction Manual

Technical data
Supply
220-240 V~, 50 Hz
Voltage:
13801 / 75434 / 7544---1 x Max. 7W LED GU10
Bulb
Type:
75436 / 75443 / 75448--1 x Max. 7W LED GU10
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
This is a Class 1 product and must be earthed.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is suitable for dimming.
This product is rated at IP44.
44
IP
Care and Safety
For your safety, always switch off the power supply before changing lightbulbs, adjusting spotlight heads or cleaning.
Do not use solvents or abrasive cleaners as these could damage the finish.
For 13801, 13802, 75448 and 75449, in normal circumstances, stainless steel is very resistant to corrosion.
It does however require maintenance to preserve the high quality appearance. Wash the product with warm soapy water,
removing all surface deposits. Rinse with clear water and with a soft cloth, wipe dry.
In some cases, surface corrosion may arise after installation. This is normally caused by tiny iron particles left behind after
the brushing process when finishing.
Wash and dry as detailed above. Then with a soft cloth soaked with a protective oil, wipe all over.
However if the product is subject to extreme environmental conditions such as marine locations, industrial pollution and acid
rain these maintenance procedures should be carried out around four times a year. For severe corrosion, non-abrasive cream
cleaners or proprietary stainless steel cleaners should be used to remove the corrosion. Wash and dry as detailed above.
Then with a soft cloth soaked with a protective oil, wipe all over.
Do not clean the units with a pressure washer.
This LED's are protected by the glass shade. The shade part must be replaced immediately should it
become cracked or damaged. This fitting must not be used without the glass shade in place.
Replace Cracked Shade
V4 12/04/2023
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
13802 / 75432 / 75439 / 94792---2 x Max. 7W LED GU10
75437 / 75444 / 75449------------2 x Max. 7W LED GU10
Instruction manual
Palin Wall & Spot
13801, 75434, 75441, 13802, 75432, 75439, 94792
75436, 75443, 75448, 75437, 75444, 75449
13801, 75434,
75441
75436, 75443,
75448
www.saxbylighting.com
13802, 75432,
75439, 94792
75437, 75444,
75449
