1.2 System Features

The following views of the system display the main features. Refer to
specifications.

Front View

Service/Asset Tag
with BMC Password
0
Item Description
0 3.5/2.5-inch front drive bay (NVMe**/SAS/SATA)* (see limitation below)
1-3 3.5/2.5-inch front drive bays (NVMe/SAS/SATA)*
* Additional parts needed depending on drive type; see the optional parts listt.
**Following Intel documentation 648608, if using four UPI processors in the server, there is a limitation on UPI3 port relating to
support for PCIe Gen5. For such configurations, the NVMe device in bay #0 is limited to PCIe 4.0.

Drive Carrier Indicators

Each drive carrier has two LED indicators: an activity indicator and a status indicator. For RAID
configurations using a controller, the meaning of the status indicator is described in the table
below. For OS RAID or non-RAID configurations, some LED indications are not supported,
such as hot spare. For VROC configurations, refer to the
Color
Activity
Blue
LED
Blue
Off
Status
Red
LED
Red
Red
Red
Red
Green
Amber
Slots for Optional Slim Drives
1
Figure 1-1. Front View
Logical Storage Drive Numbers
Drive Carrier LED Indicators
Blinking Pattern
Solid On
Blinking
Solid On
Blinking at 1 Hz
Blinking with two blinks
and one stop at 1 Hz
On for five seconds, then
off
Blinking at 4 Hz
Solid on
Blinking at 1Hz
2
VROC section in this manual.
Behavior for Device
Idle SAS/NVMe drive installed
I/O activity
Idle SATA drive installed
Failure of drive with RSTe support
Rebuild drive with RSTe support
Hot spare for drive with RSTe support
Power on for drive with RSTe support
Identify drive with RSTe support
Safe to remove NVMe drive
Do not remove NVMe drive
10
Chapter 1: Introduction
Appendix B for additional
Control Panel
3
