Control Panel

UID button
Information LED
Feature Description
The unit identification (UID) button turns on or off the blue light function of the Information
UID button/LED
LED and a blue LED on the rear of the chassis.
BMC button
This button can also be used to
Information LED Alerts operator to several states, as noted in the table below.
Indicates network activity on AIOMs when flashing. NIC LED 1 for odd ports and NIC LED 2
NIC LEDs
for even ports on both AIOM slots.
HDD Indicates activity on the storage drives when flashing.
Steady on – Power on
Blinking at 4Hz – Checking BIOS/BMC integrity
Power LED Blinking at 4Hz and "i" LED is blue – BIOS firmware updating
Two blinks at 4Hz, one pause 2hz and "i" LED blue – BMC firmware updating
Blinking at 1Hz and "i" LED red – Fault detected
Reset Button Reboots the system
The main power switch applies or removes primary power from the power supply to the server
Power button
but maintains standby power.
Color, Status
Red, solid
Red, blinking at 1Hz
Red, blinking at 0.25Hz
Red, blinking at 10Hz
Blue, solid
Blue, blinking at 1Hz
Blue, blinking at 2Hz, and BMC Heartbeat
LED on the motherboard is green
Blue, blinking at 4Hz
Blue, blinking at 10Hz
Red, blinking at 10Hz and the rear UID LED
is blue, blinking at 10Hz
Power LED
NIC LEDs
HDD LED
Figure 1-2. Control Panel
Control Panel Features
reset the BMC.
Information LED
Description
An overheating condition has occurred
Fan failure, check for an inoperative fan
Power failure, check for a non-operational
power supply
CPLD recovery mode error
Unit ID has been activated by switch
Unit ID has been activated using the BMC
BMC is resetting
BMC is setting factory defaults
BIOS/BMC is recovering or updating
CPLD recovery or update is in progress
11
Chapter 1: Introduction
Power button
Reset button
