- Page 1 2 Megapixel Network Camera User Manual Please read this manual carefully before use of the products and preserve for reference purposes. Specifications are subject to change without notice*...
- Page 2 Notes on Safety ■ Please use the specified power supply to connect. ■ Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers. ■ There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.
-
Page 3: Table Of Contents
Table of Contents Introduction ........................1 IE Remote Access ......................2 LAN ........................2 2.1.1 Access through IP-Tool ................2 2.1.2 Directly Access through IE ............... 3 WAN ........................5 Remote Preview ......................7 The Remote Preview Interface ................7 Remote Live Surveillance .................... - Page 4 Network Camera User Manual Search ........................... 27 Appendix ..........................28 Appendix 1 Q & A ......................28 Appendix 2 Specifications ....................29...
-
Page 5: Introduction
Network Camera User Manual 1 Introduction This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system more stable and reliable. -
Page 6: Ie Remote Access
Network Camera User Manual 2 IE Remote Access You may connect IP-Cam via LAN or WAN. Here only take IE browser (6.0) for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser. -
Page 7: Directly Access Through Ie
Network Camera User Manual of your device according to the practical situation. For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please input the password of the administrator and click “Modify”... - Page 8 Network Camera User Manual Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable. ①...
-
Page 9: Wan
Network Camera User Manual ② Open the IE browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control automatically. ③ After downloading Active X control, the login dialog box will pop up. ④... - Page 10 Network Camera User Manual ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and input its WAN IP and http port to access. ...
-
Page 11: Remote Preview
Network Camera User Manual 3 Remote Preview 3.1 The Remote Preview Interface After you log in, you will see the following window. The following table is the instructions of the icons on the remote preview interface. Icon Description Icon Description Motion alarm indicator Start/stop live view icon... -
Page 12: Remote Live Surveillance
Network Camera User Manual 4 Remote Live Surveillance 4.1 System Configuration The “System Configuration” includes three submenus: Basic Information, Date & Time and Local Configuration. 4.1.1 Basic Information In the Basic Information interface, you can check the relative information of the device. 4.1.2 Date &... -
Page 13: Local Configuration
Network Camera User Manual 4.1.3 Local Configuration Go to ConfigSystemLocal Config. You can set the storage path of the captured pictures and video records. 4.2 Image Configuration Image Configuration includes five submenus: Display, Video/Audio, OSD, Video Mask and ROI Config. 4.2.1 Display Configuration Many parameters of the camera can be set in display configuration interface such as brightness, contrast, chroma, saturation wide dynamic, etc. -
Page 14: Video Stream
Network Camera User Manual Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge. Denoise: Decrease the noise and make the image more thorough. Increasing the value will make the noise reduction effect better but it will reduce the image resolution. White Balance: Adjust the color temperature according to the environment automatically. -
Page 15: Osd Configuration
Network Camera User Manual used in interactive application with low complexity and delay. Main profile is mainly used for higher coding requirement. Stream of snapping photos: Please select it according to the actual situation. Video encode slice split: If enabled, you may get more fluency image even though using the low-performance PC. -
Page 16: Roi Configuration
Network Camera User Manual To set up video mask 1. Open video mask. 2. Click “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to the live to see the following picture. Clear the video mask: Go to video mask menu and then click “Clear”... -
Page 17: Alarm Configuration
Network Camera User Manual condition. 4.3 Alarm Configuration Alarm configuration includes two submenus: Motion Detection and Alarm Server. 4.3.1 Motion Detection To set motion detection: 1. Go to ConfigAlarmMotion Detection to set motion detection alarm. Check “Enable Alarm” check box to activate motion based alarm, choose alarm holding time and set alarm trigger options. - Page 18 Network Camera User Manual Move the “Sensitivity” scroll bar to set the sensitivity. Check “Add” and click “Draw” button and move mouse to select the motion detection area; Select “Erase” and move the mouse to clear motion detection area. After that, click “Save” to save the settings. 3.
-
Page 19: Alarm Server
Network Camera User Manual Set the alarm time from Monday to Sunday for alarm everyday in one week. The lengthwise means one day of a week; the rank means 24 hours of a day. Green means selected area. Blank means unselected area. “Add”: Add the schedule for a special day. -
Page 20: Port
Network Camera User Manual Use IP address. There are two options for IP setup: obtain an IP address auto by DHCP protocol and use the following IP address. Please choose one of options for your requirements. If you check “Obtain an IP address automatically”, the IP address may be changed frequently . Ten you can use the function of IP change notification. -
Page 21: Ddns Configuration
Network Camera User Manual information of the device in the ECMS/NVMS. After that, the system will auto allot a device ID. Please check it in the ECMS/NVMS. 3. Input the above-mentioned server address, server port and device ID in the responding boxes. Click “Save”... -
Page 22: Snmp
Network Camera User Manual After you successfully request your domain name, you will see your domain in the list. 3. Input the username, password, domain you apply for in the DDNS configuration interface. 4. Click “Save” button to save the settings. 4.4.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, you can set the SNMP function. -
Page 23: Rtsp
Network Camera User Manual 2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software you download. 3. Set the “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port” and so on. Please make sure the settings are the same as that of your SNMP software. Note: Please use the different version in accordance with the security level you required. -
Page 24: Upnp
Network Camera User Manual 1. Select “Enable”. 2. RTSP Port: Access port of the streaming media. The default number is 554. 3. RTSP Address: The RTSP address you need to input in the media player. 4. Check “Enable anonymous viewer login…”. 4.4.7 UPNP If you enable this function, you can quickly access the camera via LAN and you don’t need to configure the port mapping when the camera is connected to the WAN via the router. -
Page 25: Ftp Setting
Network Camera User Manual Sender Address: sender’s e-mail address; User name and password: sender’s user name and password; SMTP Address: The SMTP IP address or host name. Select the secure connection type at the Secure Connection pull down list according to user’ actual needs;... -
Page 26: Security Configuration
Network Camera User Manual To Add FTP Server Name：The name of the FTP. Server Address: The IP address or domain name of the FTP. Upload Path: The path of uploading the files. Port: The port of the FTP. Use Name and Password: The username and password are used to login the FTP. 4.5 Security Configuration 4.5.1 User Configuration Go to ConfigSecurity. - Page 27 Network Camera User Manual 2. Input user name in “User Name” textbox. 3. Input letters or numbers in “Password” and “Confirm Password” textbox. 4. Choose the use type. 5. Input the MAC address of the PC in “Binding MAC address” textbox. After binding physical address to the IP-CAM, you can access the device on this PC only.
-
Page 28: Online Video User
Network Camera User Manual Note: The default super administrator cannot be deleted. 4.5.2 Online Video User Go to ConfigSecurityOnline Video User. You can view the user who is viewing the live video. 4.5.3 Block and Allow List Go to ConfigSecurityBlock and Allow Lists. Setting steps are as follows: Check “Enable IP address filtering”... -
Page 29: Reboot Device
Network Camera User Manual Import & Export Setting: You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2. Click “Import Setting” or “Export Setting” button. ... -
Page 30: Log
Network Camera User Manual 4.6.4 Log To query and export log 1. Go to ConfigMaintenanceOperation Log. 2. Select the main type, sub type, start and end time. 3. Click “Query” to view the operation log. 4. Click “Export” to export the operation log. You can export and view the run log by clicking ConfigMaintenanceRun Log. -
Page 31: Search
Network Camera User Manual 5 Search You can play the local video record through search interface. Before playing, please set the storage path of the video record in the local configuration interface and make sure there are record files. After that, click “Search” tab on the menu toolbar. The following interface will be seen. -
Page 32: Appendix
Network Camera User Manual Appendix Appendix 1 Q & A Q: How to find my password if I forget it? A：Reset the device to the default factory settings. Default IP: 192.168.226.201 User name: admin Password: 123456 Q: Fail to connect devices through IE browser, why? A: Network is not well connected. -
Page 33: Appendix 2 Specifications
Network Camera User Manual ④ Then click OK to finish setup. b. Other plug-ins or anti-virus blocks ActiveX. Please uninstall or close them. Appendix 2 Specifications... - Page 34 Network Camera User Manual Specification /Model 20m IR Water-proof Bullet Network Camera 1/2.8＂CMOS Image Sensor 1920× 1080 Image Size Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris 0.1lux@F1.2, AGC ON; 0 lux with IR Min. llumination Camera Lens 3.6mm@F1.6, angle of view: 79° (2.8mm optional) Lens Mount Day&Night Digital WDR...
- Page 35 Network Camera User Manual Specification /Model 30m IR Water-proof Bullet Network Camera 1/2.8＂CMOS Image Sensor 1920× 1080 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.1lux@F1.2, AGC ON; 0 lux with IR Min. llumination 3.6mm@F1.6, angle of view: 79° (2.8mm, 2.8~12mm@F1.4, angle of view: 96°...
- Page 36 Network Camera User Manual Specification /Model 30m IR Water-proof 50m IR Water-proof Bullet Network Camera Bullet Network Camera 1/2.8＂CMOS Image Sensor 1920× 1080 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.1lux@F1.2, AGC ON; 0 lux with IR Min. llumination 6mm@F1.6, angle of view: 56°...
- Page 37 Network Camera User Manual 20m IR Water-proof Dome 20m IR Water-proof Dome Specification /Model Network Camera Network Camera 1/2.8＂CMOS Image Sensor 1920× 1080 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.1lux@F1.2, AGC ON; 0 lux with IR Min. llumination 3.6mm@F1.6, angle of view: 79°...
- Page 38 Network Camera User Manual Specification /Model 30m IR Water-proof Dome Network Camera 1/2.8＂CMOS Image Sensor 1920× 1080 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.1lux@F1.2, AGC ON; 0 lux with IR Min. llumination 2.8~12mm@F1.4, angle of view: 96° ~35° Camera Lens Lens Mount...
