IP PTZ Speed Camera
User Manual
Please read this manual carefully before use of the products and preserve for reference
purposes. Specifications are subject to change without notice*
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPPTZ-SB3IR20X and is the answer not in the manual?

Questions and answers

Related Manuals for SIBELL IPPTZ-SB3IR20X

Summary of Contents for SIBELL IPPTZ-SB3IR20X

  • Page 1 IP PTZ Speed Camera User Manual Please read this manual carefully before use of the products and preserve for reference purposes. Specifications are subject to change without notice*...
  • Page 2 Disclaimer ● This manual is provided for user reference only, without legal restraint. ● This manual is useful for many models. Some functions introduced in the manual may be not available for some models. Please take the real models as the standard. ●...

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Chapter 2 IE Remote Access 2.1.1 Access through IP-Tool 2.1.2 Directly Access through IE Chapter 3 Remote Preview Chapter 4 Menu Setup System Information System Setup 4.2.1 Auto PT Flip 4.2.2 Language Setup 4.2.3 RS485 Setup 4.2.4 Date Setup 4.2.5...
  • Page 4 5.1.4 SD Card Image Configuration 5.2.1 Video / Audio Configuration 5.2.2 OSD Configuration 5.2.3 Camera Setup PTZ Configuration 5.3.1 PTZ and Password Setting 5.3.2 Load Default 5.3.3 Dome Function Alarm Configuration 5.4.1 Motion Detection 5.4.2 Alarm Input 5.4.3 Alarm Out 5.4.4 Alarm Server Network Configuration...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction This IP speed dome camera is front-end equipment used for video capture. Its digital flip technology makes omni-directional and non-blind-spot monitoring a reality. It utilizes most advanced technologies, such as video encoding and decoding technology, and complies with the TCP/IP protocol, SoC., etc., to ensure this system more stable and reliable.

  • Page 6: Chapter 2 Ie Remote Access

    Chapter 2 IE Remote Access You may connect IP-Cam via LAN or WAN. Here we use IE browser (6.0) for example. The details are as follows: In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.
  • Page 7 ③ Modify the IP address. The default IP address of this camera is 192.168.226.201. Click the information of the camera listed in the above table to show the network information on the right hand. Modify the IP address and gateway of the camera and make sure its network address is in the same local network segment as the computer’s.

  • Page 8: Directly Access Through Ie

    ☞ The default username is “admin”; the default password is “123456”. 2.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201 Subnet Mask: 255.255.255.0 Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable.
  • Page 9 ② Open the IE browser and input the default address of IP-Cam and connect. The IE browser will download Active X control automatically. **IMPORTANT: You must configure IE Internet options before the Active X control will install. Proceed to do the following in Internet Explorer: Click on Tools (cog wheel top right corner) >...

  • Page 10: Wan

    ③ After downloading Active X control, the login dialog box will pop up. ④ Input the default username and password and then enter to view camera, and access camera settings. WAN (Router) ➢ Access through the router ① Make sure the camera is well connected via LAN and then log into the camera via LAN and go to ConfigNetwork Port menu to set the port number.
  • Page 11 ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera. Login to the router by typing in the default gateway address into the web address bar of the browser (ex. http://192.168.1.1). Navigate to the Port forwarding, Virtual Server, Custom service, or Pinhole section in the router.
  • Page 12 ➢ Access through PPPoE dial-up Network connection You may access the camera through PPPoE auto dial-up. ① Go to ConfigNetwork Port menu to set the port number. ② Go to Config Network TCP/IPv4 menu. Check “PPPoE Config” and then input the user name and password, which you can get from your internet service provider.

  • Page 13: Chapter 3 Remote Preview

    ① Go to ConfigNetwork Port menu to set the port number. ② Go to Config Network TCP/IPv4 menu to set the IP address. Check “Use the following IP address” and then input the static IP address and other parameters. ③ Open the IE browser and input its WAN IP and http port to access. Chapter 3 Remote Preview After you log in, you will see the following window.
  • Page 14 Full screen Zoom in Start/stop live view Zoom out Start/stop two-way talk PTZ control Move the cursor to view the live image in all directions after you click this button. Additionally, hold and drag the left mouse button to zoom in the live image.

  • Page 15: Chapter 4 Menu Setup

    Chapter 4 Menu Setup On the PTZ control panel of IE remote preview interface, call Preset 95 and click . This will take you to see the following main menu setup. ☞ The menu setup can be displayed when the resolution of the live is set to 1920×1080. After you go to the main menu interface, you can select the menu by clicking the direction button ( ：Select to move up or down.

  • Page 16: System Setup

    You can check the software and firmware version, camera, system temperature, date, dome ID, dome protocol and baud rate here. 4.2 System Setup Select System Setup by clicking button and then click button to enter System Setup as shown below: 4.2.1 Auto PT Flip Select Auto PT Flip and then click to set up the menu on the right;...

  • Page 17: Date Setup

    【Dome ID】: The available range is from 001 to 255. 【Protocol】: PELCOD or PELCOP is selectable. 【Baud Rate】: The baud rate is selectable from 1200 to 9600bps. 4.2.4 Date Setup Go to System SetupDate Setup menu as shown below: Set the date and time by clicking the direction button. Select STORE to save the setting.

  • Page 18: North Setup

    4.2.6 North Setup Go to System SetupNorth Setup as shown below: Choose a location by clicking the direction button. Select STORE to save the setting. The horizontal angle will treat the north position as a reference; otherwise, it will treat the horizontal origin as a reference to display the clockwise rotation angle of camera.

  • Page 19: Camera Setup

    ➢ Enter the current password and then input the new password twice. (Please refer to “New Password” for details.) ➢ Inputting empty new password means to delete the current password. 4.2.8 Auto Exit Time Go to System SetupNext PageAuto Exit Time. You can set a time for the menu to exit automatically.

  • Page 20: Image Setup

    【BLC】：When the background light is so strong that the foreground is dark, the brightness of the whole image will improve by enhancing the visibility of the foreground image when the BLC function is enabled. 【HLC】： If enabled, the darker parst will be lightened, while the highlight part will be suppressed.
  • Page 21 ● AE Setup Go to AE Setup menu as shown below: 【AE MODE】: Auto, Bright, Shutter, IRIS, and Manual are optional. 【Brightness】： Range from 0（darkest）~20（brightness）. It is available only when bright mode is selected. 【Shutter】：The lower the value of camera shutter is, the brighter the image is. It is available only when the shutter or manual mode is selected.

  • Page 22: Lens Setup

    【WB Mode】：White Balance Mode. There are two options you can choose including auto and manual. You can select the mode according to different lighting condition. 【MWB Red Gain】：The operation is effective in manual mode. 【MWB Blue Gain】：The operation is effective in manual mode. [AGC] The larger the number is, the higher the brightness and the more the noise in the image ●...

  • Page 23: Day & Night Setup

    ● Zoom Speed Adjust zoom speed. The range is from 1 to 8. ● DZoom After enabling digital zoom mode, digital zoom will be increased on the basis of optical zoom. ● Len Initialize After enabling “Len Initialize”, the camera lens will restore to factory default. 4.3.4 Day &...

  • Page 24: Preset Setup

    4.4.1 Preset Setup This function is used to memorize the specific position of pan, tilt, zoom and focus, giving convenience for quick return to a position by calling preset. Selecting the preset setup menu brings up the following menu. Select the preset number. Go to Edit CUR Preset interface as below: Press iris –...
  • Page 25 4.4.2 Cruise Setup (Tour) Go to Dome FunctionCruise Setup menu as below: In this interface, by programming presets in cruise list in advance, the system will keep calling those presets at the set time in sequence when executing cruise command so that non-stop monitoring between multiple important positions can be achieved.

  • Page 26: Grouping Setup

    4.4.3 Grouping Setup Go to Dome FunctionGrouping Setup as below: Go to “Edit Grouping” menu as shown below. 8 cruises can be set in a group. CRU 1 stands for Cruise 1, CRU 2 stands for Cruise 2 and so on.

  • Page 27: Track Setup

    Time Format: Start Time – End Time. The tasks will be automatically executed in chronological order. Task Type: RSC, ASC, PRE, CRU, TRA. ☞ Note: The home position function will be disabled if enabling task setting. 4.4.5 Track Setup Go to Dome FunctionTrack Setup menu as shown below: This function is used to memorize the operation of the PTZ, zoom and focus so that repeating operation progress can be realized by running track.

  • Page 28: Alarm Setup

    automatically save the first 360 commands and then exit the current menu. The recording time is related to the operating frequency. The more frequent the operation is, the shorter the memory time is. Select “RUN CUR TRACK…” to perform the command. 4.4.6 Alarm Setup Go to Dome FunctionAlarm Setup as shown below: Setting Steps:...

  • Page 29: Privacy Mask

    4.4.7 Privacy Mask   Go to the Main Menu Dome Function Privacy Mask menu as below: 【Mask NO.】：Set the current mask area. 8 mask areas can be set at most. 【Mask Color】：Select the color to mask. 【Mask Display】：If “ON” is selected, the mask area will be displayed on the live interface.

  • Page 30: Display Setup

    The setting steps: Enable the home position function and select the preset ,which should be set in advance. Then select delay time (range from 007s to 180s) and exit the menu. When the stand-by time of the dome camera exceeds the delay time, the camera will automatically execute the command to monitor the selected preset.
  • Page 31 not clear those parameters such as preset and cruise. 【Master Clear】：Restore the camera to factory default. 【System Reboot】：Reboot the camera.

  • Page 32: Chapter 5 Remote Configuration

    Chapter 5 Remote Configuration 5.1 System Configuration The “System configuration” includes four sub-menus: Basic Information, Date and Time, Local Config and SD Card. 5.1.1 Basic Information In the Basic Information interface, you can check the relative information of the device. 5.1.2 Date and Time Configuration Go to ConfigSystemDate and Time.

  • Page 33: Sd Card

    5.1.3 Local Config Go to ConfigSystemLocal Config. You can set the storage path of the captured pictures and video records. 5.1.4 SD Card Go to ConfigSystemSD Card. In the above interface, you can check the capacity, used capacity, remaining capacity and state of the SD card.

  • Page 34: Image Configuration

    5.2 Image Configuration Image Configuration includes three submenus: Video/Audio, OSD and Camera Setup. 5.2.1 Video / Audio Configuration The following interface will be displayed by clicking ConfigImageVideo/Audio. In this interface, you can set the resolution, frame rate, bitrate type, video quality and more, subject to the actual network condition.

  • Page 35: Ptz Configuration

    You may set time stamp, device name, and OSD here. After enabling the corresponding display and entering the content, drag them to change their position. Then press the “Save” button to save the settings. 5.2.3 Camera Setup   Go to Config Image Camera Setup.

  • Page 36: Load Default

    In this submenu, PTZ title, date, auto PTZ flip, language, and menu keeping time can be set. If your model support RS485 interface, you may configure the communication setting for keyboard control.  Password Setting If the password is set, you must input the password every time you go to the menu of the PTZ. Go to ConfigPTZSettingOthers, here you can set the password of the PTZ menu.
  • Page 37 Check “Enable Alarm” check box to activate motion based alarm, choose alarm holding time and set alarm trigger options. Alarm Out: If selected, this would trigger the external relay output on detecting a motion based alarm. Trigger Snap: If selected, the system will snap images on an alarm and save them in SD card. Trigger Email: If the email and attach picture checkbox is checked (Email address shall be set first in the Mail config interface), the triggered snap pictures and event will be sent to the designated email address(es).
  • Page 38 Move the “Sensitivity” scroll bar to set up the motion track sensitivity. Check “Add”, click “Draw” button and move mouse to select the motion detection area; Select “Erase” and move the mouse to clear motion detection area. After that, click “Save” to save the settings. 3.
  • Page 39 Week schedule You can set an alarm schedule for any day of the week, Monday to Sunday. Add: Add the schedule for a special day. Erase: Delete holiday schedule. Day schedule You can set alarm time for a holiday or special circumstance. 1.

  • Page 40: Alarm Out

    ● Set the alarm type, alarm holding time and sensor name. ● Enable alarm. ● Set alarm trigger options. The setting steps are the same with that of motion detection. Please refer to motion detection chapter for details. ● Click “Save” to save the settings. If there are many sensors, you can Copy and paste to quickly apply settings to other sensors.

  • Page 41: Alarm Server

    2. Select alarm holding time and alarm name 3. Click “Open” to trigger alarm output. Click “Close” to stop alarm output. 4. Press the “Save” button to save the settings. 5.4.4 Alarm Server  Go to “Alarm configuration” “Alarm Server” interface is shown below. You may input the alarm server address and port.
  • Page 42 ● Use IP address. Obtain an IP address automatically by DHCP protocol or use the following IP address. ● Use PPPoE: Enter the username and password from your ISP. If you use PPPoE to connect internet, you will get a dynamic WAN IP address. This IP address will change frequently.

  • Page 43: Port

    RTSP Port: The default port is 554. You may change as needed. 5.5.3 Central Server This function is mainly used for connecting to Sibell NVMS 1. Check “Enable”. 2. Check the IP address and port of the transfer media server in the ECMS/NVMS. Then enable the auto report in the ECMS/NVMS when adding a new device.
  • Page 44 2. Apply for a domain name. Take www. dvrdyndns.com for example. Input www.dvrdydns.com in the IE address bar to visit its website. Then click the “Registration” button to register as shown below. Create domain name.
  • Page 45 After you successfully request your domain name, you will see your domain in the list. 3. Input the username, password, and domain name you apply for in the DDNS configuration interface. 4. Click “Save” button to save the settings. 5.5.5 SNMP To get camera status, parameters, alarm information and remotely manage the camera, you can set the SNMP function.

  • Page 46: Rtsp

    5.5.6 RTSP Go to ConfigNetworkRTSP.

  • Page 47: Upnp

    1. Select “Enable”. 2. RTSP Port: Access port of the streaming media. The default number is 554. 3. RTSP Address: The RTSP address you need to input in the media player. 4. Check “Enable anonymous viewer login…”. 5.5.7 UPnP If you enable this function, you can quickly access the camera via LAN and you don’t need to configure the port mapping when the camera is connected to the WAN via the router.
  • Page 48 Sender Address: sender’s e-mail address; User name and password: sender’s user name and password; SMTP Address: SMTP server address (ex. smtp.gmailx.com). SMTP Port: The SMTP port. Secure connection: Select according to the smtp server authentication requirements. Send Pictures: Check if you want to send emails with attached alarm images. Click “Test Account Settings”...

  • Page 49: Security Configuration

    Server Name：The name of the FTP. Server Address: The IP address or domain name of the FTP. Port: The port of the FTP. Use Name and Password: The username and password are used to login the FTP. Upload Path: The path of uploading the files. Send Pictures: If enabled, the captured pictures will be uploaded to FTP.
  • Page 50 2. Input username in “User Name” textbox. 3. Input letters or numbers in “Password” and “Confirm Password” textbox. 4. Choose the user type. 5. Input the MAC address of the PC in “Binding MAC address” textbox. After binding physical address to the IP-CAM, you can access the device on this PC only. 6.

  • Page 51: Online Video User

    Delete user: 1. Select the user you want to delete in the user configuration list box. 2. Click “Delete” button to delete the user. Note: The default super administrator cannot be deleted. 5.6.2 Online Video User Go to ConfigSecurityOnline Video User. You can view the user who is viewing the live video.

  • Page 52: Maintenance

    5.7 Maintenance 5.7.1 Backup & Restore Go to ConfigMaintenanceBackup & Restore. ● Import & Export Setting: You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2.
  • Page 53 1. Click “Browse” button to select the save path of the upgrade file 2. Click “Upgrade” button to start upgrading the application program. 3. The device will restart automatically 4. After you successfully update the software, click “OK” button to close IE and then re-open IE to connect IP-Cam.

  • Page 54: Chapter 6 Playback

    Chapter 6 Playback Photo Search Click “Search” icon to search the photos saved in the SD card. 1. Set time: Select date and choose the start and end time. 2. Choose “Motion” or “Sensor”. 3. Click “Search” button to search the picture. 4.

  • Page 55: Video Search

    Item Buttons Explanations Close: Select certain picture and click this button to close this picture. Close all: Click this button to close all pictures viewing. Save: Click this button to select the save path of the picture file on the PC for saving the current picture. Save all: Click this button to select the save path of the picture files on PC for saving all pictures.
  • Page 56 Choose the date, the start time and end time and then click “Search” button to search the recording files. Double click the recording to play. The descriptions of the buttons on the playback interface are as follows. Button Description Play button. After pausing the video, click this button to continue playing.

  • Page 57: Chapter 7 Q & A

    Chapter 7 Q & A 1. Q: How do I find my password if I forget it? Reset the system to the factory default setting or contact the dealer. Default IP: 192.168.226.201 User name: admin Password: 123456 2. Q：The devices can’t connect through IE browser. Why? A：It may be caused by the anti-virus and Windows Firewall/Windows Defender on your computer.

  • Page 58: Appendix Preset Description

    Appendix Preset Description Call NO.90 Preset Run track 1 Call NO.91 Preset Run cruise 1 Call NO.92 Preset Run cruise 2 Call NO.93 Preset Run cruise 3 Call NO.94 Preset Run cruise 4 Call Preset Call NO.95 Preset OSD menu Call NO.97 Preset Enable random scan Call NO.99 Preset...
