Page 1: User Manual
4 Megapixel Network Camera User Manual For Varifocal Lens Bullet & Dome Camera Please read this manual carefully before use of the products and preserve for reference purposes. Specifications are subject to change without notice*... -
Page 2: Notes On Safety
Notes on Safety ■ Please use the specified power supply to connect. ■ Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers. ■ There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure. - Page 3 Introduction IE Remote Access 2.1.1 Access through IP-Tool 2.1.2 Directly Access through IE Remote Preview The Remote Preview Interface Playback Snap Pictures Remote Live Surveillance System Configuration 4.1.1 Basic Information 4.1.2 Date & Time 4.1.3 SD Card Video Configuration 4.2.1 Camera 4.2.2 Video Stream...
- Page 4 1 Introduction This IP-Cam (short for IP-Camera) is designed for high performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system more stable and reliable.
-
Page 5: Ie Remote Access
2 IE Remote Access You may connect IP-Cam via LAN (Local Area Network) or WAN (Wide Area Network). The details are as follows: LAN (Local network) In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser. -
Page 6: Directly Access Through Ie
the information of the camera listed in the above table to show the network information on the right hand. Modify the IP address and gateway of the camera and make sure its network address is in the same local network segment as the computer’s. Please modify the IP address of your device according to your local network configuration. - Page 7 ① Manually set the IP address of the PC. The network segment should be as the same as the default settings of the IP camera. Open Network and Sharing Center in Windows Control Panel. Click “Change adapter settings,” Right-click “Local Area Connection” and choose Properties, Left-click on “Internet Protocol TCP/IP v4,”...
- Page 8 ③ After downloading Active X control, the login dialog box will pop up. ④ Input the default username and password and then enter to view camera, and access camera settings. WAN (Router) ➢ Access through a router ① Make sure the camera is well connected via LAN and then login the camera via LAN and go to ConfigNetwork ConfigPort menu to set the port number.
- Page 9 IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera. Login to the router by typing in the default gateway address into the web address bar of the browser (ex. http://192.168.1.1). Navigate to the Port forwarding, Virtual Server, Custom service, or Pinhole section in the router.
- Page 10 ② Go to Config Network ConfigIP Address menu. Check “PPPoE” and then input the username and password which you can get from your internet service provider. ③ Go to Config Network ConfigDDNS Config menu. Before you configure the DDNS, please apply for a domain name first. Please refer to 4.4.5 DDNS Configuration for detail information.
-
Page 11: The Remote Preview Interface
3 Remote Preview The Remote Preview Interface Icon Descriptio Icon Descriptio Motion alarm Sensor alarm indicator icon indicator icon Fix size Start/Stop record Actual size Playback Zoom in Snap Zoom out Talk Fullscreen Enable audio When motion detection alarm is triggered, the people icon will turn red. Right click to pop up a pull-down list as shown below:... - Page 12 Stream: Three streams are optional. Turn off the live: Click this item to close present live preview. Enable audio: Open the volume. Full screen: The live preview picture will be full-screen display. Double click or click right mouse to return to the previous interface.
-
Page 13: Snap Pictures
Play Next frame Zoom out Pause The previous file Full screen Stop The next file Path Forward Zoom in Volume Snap Pictures Select the image frame number, and then click “Snap” icon as shown below: Single Snap Snap multiple pictures: Select the image frame number pull down list box, such as 2, and check “Title”... -
Page 14: Remote Live Surveillance
Multi-picture Snap 4 Remote Live Surveillance Functions of remote configurations include System Configuration, Video Configuration, PTZ Configuration, Alarm Configuration, Network Configuration and Advanced Configuration. You should select the menu on the left and then set up the relative parameters. System Configuration The “System configuration”... -
Page 15: Date And Time
Please refer to the following table for parameters and instructions of server basic configuration. Parameter Meaning Software version The software of the device Software build date The software build date of the device Kernel version The kernel version of the device Hardware version The hardware version of the device Mac Address... -
Page 16: Video Configuration
The first time you use the SD card, you should click “Format SD card”. Click “Eject card” to stop writing data to SD card. Then the SD card can be ejected safely. ☞ Note: Using of SD card function should be coordinated with motion or sensor alarm. -
Page 17: Osd Configuration
Three video streams can be adjustable. Resolution: The higher the resolution is, the clearer the image is. Frame rate: The higher the frame rate is, the more fluent the video is. However, it increases amount of storage space required. Higher frame rate = less video storage Bitrate type: Including CBR and VBR. -
Page 18: Video Mask
You may set time stamp, device name and custom OSD here. Drag the time stamp and custom OSD to set their position. Then press the “Save” button to save the settings. 4.2.4 Video Mask Go to “Video Config” “Video Mask” menu to display the interface. You can set 4 mask areas at most. -
Page 19: Roi Configuration
Clear the video mask: Go to video mask menu and then click “Clear” button to delete the current video mask area. 4.2.5 ROI Configuration To set up ROI 1. Go to Video ConfigROI Config menu. 2. Check “Enable” and then click “Draw” button. 3. -
Page 20: Ptz Configuration
PTZ Configuration PTZ Configuration includes two submenus: Protocol and Preset. 4.3.1 Protocol 1. Go to “PTZ Configuration” “Protocol” interface as shown below: 2. Input the protocol, address, and baud rate according to the speed dome. 4.3.2 Preset Configuration 1. Go to “PTZ Configuration” “Preset” to see an interface as shown below: Button Meaning... -
Page 21: Alarm Configuration
to rotate the dome upwards; to rotate the dome downwards; rotate the dome towards left; to rotate the dome towards right; stop rotating the dome. Focus button. Click button to have long focus; click button to have short focus. Zoom button. Click button to zoom in the locale picture ;... -
Page 22: Motion Detection Schedule
2. Check “Enable alarm” check box. Then motion based alarm is activated. 3. Set alarm holding time. 4. Set alarm trigger options. Alarm Out: If selected, this would trigger the external relay output on detecting a motion based alarm. Trigger Snap: If selected, the system will snap images on an alarm and save them in SD card. Trigger Email: If the email and attach picture checkbox is checked (Email address shall be set first in the Mail config interface), the triggered snap pictures and event will be sent to the designated email address(es). -
Page 23: Alarm Input Trigger
Week schedule You can set the alarm time from Monday to Sunday for alarm everyday in one week. Add: Add the schedule for a special day. Erase: Delete holiday schedule. Day schedule You can set alarm time for a holiday or special circumstance. 1. -
Page 24: Alarm Out
1. Select the sensor. 2. The following setup steps are similar to Motion Detection Schedule. Please refer to Motion Detection Schedule chapter for more details. 4.4.6 Alarm Out 1. Go to “Alarm configuration” “Alarm output” as shown below: 2. Select alarm holding time and alarm name at the “Alarm out” and “Alarm holding time” pull down list box respectively. -
Page 25: Network Configuration
Network Configuration Network configuration includes nine submenus: Port, IP Address, Server Configuration, IP Notify, DDNS Config, RTSP, UPNP, Mail configuration, and FTP. 4.5.1 Port 1. Go to “Network config” “Port” to see the interface as shown below. *Note: you do not need to change the ports if only 1 camera is being installed 2. -
Page 26: Server Configuration
Set up IP address change notice. Connect with Modem. Then the device will dial up internet automatically. Press the “Save” button to save the settings. 4.5.3 Server Configuration Go to “Network Configuration” “Server Config”. 1. Check “Do you want IP Camera to connect Server”. 2. - Page 27 2. Apply for a domain name. Take WWW. dvrdydns.com for example. in the IE address bar to visit its website. Then click “Registration” Input www.dvrdydns.com button to register as shown below. Create domain name. After you successfully request your domain name, you will see your domain in the list. 3.
-
Page 28: Mail Configuration
4.5.6 RTSP Go to “Network Configuration” “RTSP” interface as shown below. 1. Select “Enable RTSP server”. 2. RTSP Port: Access Port of the streaming media. The default number is 554. 3. RTSP Address: The RTSP address you need to input in the media player. 4. - Page 29 1. From Email: sender’s e-mail address. 2. User name and password: sender’s user name and password. 3. Server address: SMTP server address (ex. smtp.gmailx.com). 4. Select the secure connection type at the Secure Connection pull down list according to the smtp server authentication requirements.
-
Page 30: Advanced Configuration
User name The user name of the FTP server Password The password of the FTP server Path The save path for FTP files Advanced Configuration Advanced configuration includes five submenus: User Configuration, Security Configuration, Configure Backup & Restore, Reboot, and Upgrade. 4.6.1 User Configuration Go to Advanced configurationUser Configuration interface. -
Page 31: Security Configuration
Modify User 3. Input original password of this user in the “Password” text box. 4. Input new password in the “New password” and “Confirmation” text box. 5. Input computer’s physical address which is used to access the server in the “User PC MAC” text box. -
Page 32: Configure Backup & Restore
4.6.3 Configure Backup & Restore Go to Advanced configurationConfigure Backup & Restore Interface. ● Import & Export Configuration: You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2. - Page 33 4.6.5 Upgrade Go to Advanced Configuration—Upgrade interface as shown below. 1. Click “Browse” button to select the save path of the upgrade file. 2. Click “Upgrade server firmware” button to start upgrading the application program. 3. The device will restart automatically. 4.
-
Page 34: Video Search
5 Video Search Click “Picture” icon and search the images saved in the SD card. Set time: Select date in the “Calendar” and choose the start and end time. Choose event “Motion” or “Sensor”. Click “Search” button to search the picture. Double click a filename or select a filename and then click “View”... - Page 35 Item Buttons Explanations Close: click this button to close the picture chosen. Close all: Click this button to close all pictures viewing. Save: Click this button to select the save path of the picture file on the PC for saving the current picture. Save all: Click this button to select the save path of the picture files on PC for saving all pictures.
-
Page 36: Appendix 1 Q & A
Appendix Appendix 1 Q & A Q: How to find my password if I forget it? A：Reset the device to the default factory settings. Default IP: 192.168.226.201; Username: admin; Password: 123456 Q：Fail to connect devices through IE browser, why? A: Network is not well connected. Check the connection and make sure it is connected well. B: IP is not available. -
Page 37: Appendix 3 Specifications
Please mount the rubber plug to the gap of the mounting base. Please let the camber surface of the rubber plug mount outside. Appendix 3 Specifications Specification /Model 50m IR Water-proof Bullet Network Camera Image Sensor 1/3＂CMOS Image Size 2688×1520 Electronic Shutter 1/25s~1/100000s Auto Iris... - Page 38 Audio MIC IN×1; MIC OUT×1 Storage Support TF card, up to 64GB RS485 Support Alarm 1CH alarm input; 1 CH alarm output Remote Monitoring IE browser, CMS remote control Online Connection Support simultaneous monitoring for up to10 users and multi-stream transmission Network Protocol TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP Function...
- Page 39 IR Distance 20~30 m Protection Grade IP66&IK10 Power DC12V/PoE Power Consumption < 2.5W(ICR OFF); < 5W(ICR ON) Operating Others Temperature: -20°C~50°C; Humidity: 10%~90% Environment Dimension (mm) Ø150mm×114mm Weight（net） 1260g Installation Pendent mounting (wall mounting available with junction box and bracket)
