Page 1: User Manual
8 Megapixel Network Camera User Manual Please read this manual carefully before use of the products and preserve for reference purposes. Specifications are subject to change without notice*... - Page 2 Notes on Safety ■ Please use the specified power supply to connect. ■ Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers. ■ There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.
-
Page 3: Table Of Contents
Table of Contents Introduction IE Remote Access 2.1.1 Access through IP-Tool 2.1.2 Directly Access through IE Remote Preview The Remote Preview Interface Playback Snap Pictures Remote Live Surveillance System Configuration 4.1.1 Basic Information 4.1.2 Date & Time Video Configuration 4.2.1 Camera 4.2.2 Video Stream... -
Page 4: Introduction
1 Introduction This IP-CAMERA is designed for high-performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system is stable and reliable. -
Page 5: Ie Remote Access
IE Remote Access You may connect IP-Cam via LAN (Local Area Network) or WAN (Wide Area Network). The details are as follows: LAN (Local network) In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser. - Page 6 Click the information of the camera listed in the above table to show the network information on the right hand. Modify the IP address and gateway of the camera and make sure its network address is in the same local network segment as the computers. Please modify the IP address of your device according to your local network configuration.
-
Page 7: Directly Access Through Ie
1.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201 Subnet Mask: 255.255.255.0 Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through a network cable. -
Page 8: Wan
② Open the IE browser and input the default address of IP-Cam and connect. The IE browser will download Active X control automatically. **IMPORTANT: You must configure IE Internet options before the Active X control will install. Proceed to do the following in Internet Explorer: Click on Tools (cog wheel top right corner) >... - Page 9 ② Go to Config Network ConfigIP Address menu to modify the IP address. IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera. Login to the router by typing in the default gateway address into the web address bar of the browser (ex.
-
Page 10: Remote Preview
② Go to Config Network ConfigIP Address menu. Check “PPPoE” and then input the username and password which you can get from your internet service provider. ③ Go to Config Network ConfigDDNS Config menu. Before you configure the DDNS, please apply for a domain name. Please refer to 4.4.5 DDNS Configuration for detail information. -
Page 11: The Remote Preview Interface
The Remote Preview Interface People icon Full screen Fix size Start recording Actual size Playback Zoom in Snap Zoom out Enable audio When motion detection alarm is triggered, the people icon will turn red. Right click to pop up a pull-down list as shown below:... -
Page 12: Playback
Stream: Three streams are optional. Turn off live: Click this item to close live preview. Enable audio: Open the volume control. Full screen: The live preview picture will be full-screen display. Double click or click right mouse to return to the previous interface. Online user: Display the current user connected to the device. -
Page 13: Snap Pictures
Snap Pictures Select the image frame number, and then click “Snap” icon as shown below: Single Snap Snap multiple pictures: Select the image frame number pull down list box, such as 2, and check “Title” and “Time” to show capture title and time on the snap pictures simultaneously. Multi-picture Snap... -
Page 14: Remote Live Surveillance
3 Remote Live Surveillance Functions of remote configurations include System Configuration, Video Configuration, Alarm Configuration, Network Configuration and Advanced Configuration. You should select the menu on the left and then set up the relative parameters. System Configuration The “System configuration” includes two submenus: Basic Information and Date & Time. 3.1.1 Basic Information In the “Basic Information”... -
Page 15: Video Stream
3.2.1 Camera Setting steps: 1. Go to “Video Configuration” “Camera” interface as shown below. 2. You may adjust frequency, brightness, contrast, hue and saturation of the picture. 3. Select white balance mode. 4. Wide dynamic, sharpen and denoise are adjustable. 5. -
Page 16: Osd Configuration
quality better in a constant bitrate but also help to calculate the capacity of the recording. VBR means that the compression bitrate can be adjustable according to the change of the video resources. This will help to optimize the network bandwidth. Video Quality: When VBR is selected, you need to choose image quality. -
Page 17: Roi Configuration
To set up video mask 1. Enable video mask. 2. Click “Draw” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to live view to see the following picture. Clear the video mask: Go to video mask menu and then click “Clear”... -
Page 18: Alarm Configuration
Alarm Configuration Alarm configuration includes four submenus: Motion Detection Area, Motion Detection Trigger, Motion Detection Schedule and Alarm Server. 3.3.1 Motion Detection Area 1. Go to “Alarm configuration” “Motion Detection Area” to see the interface below. 2. Move the “Sensitivity” scroll bar to set up the motion trace sensitivity. 3. -
Page 19: Motion Detection Trigger
3.3.2 Motion Detection Trigger 1. Go to “Alarm Configuration” “Motion Detection Trigger” to display an interface as shown below. 2. Check the “Enable alarm” box. Then all functions under this interface will be activated. 3. Trigger Email: If the email and attach picture checkbox is checked (Email address shall be set first in the Mail config interface), the triggered snap pictures and event will be sent to the designated email address(es). -
Page 20: Alarm Server
Week schedule You can set an alarm schedule for any day of the week, Monday to Sunday. Add: Add a special day to the schedule. Erase: Delete holiday schedule. Day schedule You can set the alarm time for a holiday or special circumstance. 1. -
Page 21: Server Configuration
There are two options for IP setup: obtain an IP address auto by DHCP protocol and use the following IP address. You may choose one of the options as required. Use the following IP address: display the IP address, subnet mask, gateway and DNS of the device PPPoE: User needs to input the username and password for dial-up internet. -
Page 22: Ip Notify
4. Click “Save” button to save the settings. 3.4.4 IP Notify 1. Go to “Network Configuration” “IP Notify” to see a tab as shown below. 2. If the “Enable notifying change of IP” is selected, when the IP address of the device is changed, a new IP address will be sent to the appointed mailbox automatically;... -
Page 23: Rtsp
After you successfully request your domain name, you will see your domain in the list. 3. Select the server type and then input your username, password and domain name for the DDNS configuration interface. 4. Click “Save” button to save the settings. 3.4.6 RTSP Go to “Network Configuration”... -
Page 24: Mail Configuration
icon. 3.4.8 Mail configuration Go to “Network Configuration” “Mail configuration” interface. 1. From Email: sender’s e-mail address. 2. Username and password: sender’s username and password. 3. Server address: SMTP server address (ex. smtp.gmailx.com). 4. Select the secure connection type at the Secure Connection to pull down the list according to the smtp server authentication requirements. -
Page 25: User Configuration
Please refer to the following table for parameters and instructions of FTP configuration. Parameter Meaning Server name The name of the FTP server Server address The address of the FTP server Port The port number of the FTP server 3.5 Advanced Username The username of the FTP server Password... -
Page 26: Security Configuration
1. Select the user you need to modify. 2. Clicking “Modify” button will pop up “Modify user” dialog box as shown below. Modify User 3. Input original password of this user in the “Password” text box. 4. Input new password in the “New password” and “Confirmation” text box. 5. -
Page 27: Configure Backup & Restore
3.5.3 Configure Backup & Restore Go to Advanced configurationConfigure Backup & Restore . ● Import & Export Configuration: You can import or export the setting information from PC or to device. 1. Click “Browse” to save path for import or export information on PC. 2. - Page 28 1. Click “Browse” button to select the save path of the upgrade file. 2. Click “Upgrade server firmware” button to start upgrading the application program. 3. The device will restart automatically. 4. After you successfully update the software, click “OK” button to close IE and then reopen IE to connect IP-CAM.
-
Page 29: Appendix
Appendix Appendix 1 Q & A Q: How do I find my password if I forget it? A：Reset the device to the default factory settings. Default IP: 192.168.226.201 Username: admin Password: 123456 Q：Fail to connect devices through IE browser, why? A: Network is not well connected. -
Page 30: Appendix 2 Specifications
Appendix 2 Specifications 20m IR Waterproof 30m IR Waterproof Bullet Specification /Model Bullet Network Camera Network Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Min. illumination 0.05lux@F1.2, AGC ON: 0 lux with IR 3.6mm@F1.6, angle 2.8~12mm@F1.4, 3.6mm@F1.6, angle of view: 77°;... - Page 31 50m LED IR Array Network 50m IR Water-proof Bullet Specification /Model Network Camera Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Min. illumination 0.05lux@F1.2, AGC ON: 0 lux with IR 2.8~12mm@F1.4, 3.6mm@F1.6, angle of view: 77°; (2.8mm, Camera Lens the angle of view: 89°~34°...
- Page 32 Specification /Model Waterproof Mini Dome Network Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Min. illumination 0.05lux@F1.2, AGC ON: 0 lux with IR Camera Lens 3.6mm@F1.6, angle of view: 77°; (2.8mm, 6mm optional) Lens Mount Day&Night Digital WDR Digital NR...
- Page 33 Specification /Model Water-proof Dome Network Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Color: 0.05lux@ F1.2, AGC ON: 0 lux Min. llumination 0.05lux@ F1.2, AGC ON: 0 lux with IR with IR; B/W: 0.01lux@ F1.2, AGC ON Camera 2.8~12mm@F1.4,...
- Page 34 Specification /Model 20m IR Waterproof Dome Network Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Min. illumination 0.05lux@F1.2, AGC ON: 0 lux with IR Camera Lens 3.6mm@F1.6, angle of view: 77°; (2.8mm, 6mm optional) Lens Mount Day&Night Digital WDR...
- Page 35 Specification /Model 30m IR Waterproof Dome Network Camera 1/2.7＂CMOS Image Sensor Image Size 1920×1080 Electronic Shutter 1/25s~1/100000s Auto Iris Fixed Iris Min. illumination 0.05lux@F1.2, AGC ON: 0 lux with IR Camera Lens 2.8~12mm@F1.4, angle of view: 89°~34° Lens Mount Ø14 Day&Night Digital WDR Digital NR...
