Ir water-proof bullet network camera
Hide thumbs Also See for IPOD-SB3IREV:
Table of Contents

Advertisement

Quick Links

Download this manual
3 Megapixel Network Camera
User Manual
Please read this manual carefully before use of the products and preserve for reference
purposes. Specifications are subject to change without notice*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPOD-SB3IREV and is the answer not in the manual?

Questions and answers

Related Manuals for SIBELL IPOD-SB3IREV

Summary of Contents for SIBELL IPOD-SB3IREV

  • Page 1 3 Megapixel Network Camera User Manual Please read this manual carefully before use of the products and preserve for reference purposes. Specifications are subject to change without notice*...
  • Page 2 Notes on Safety ■ Please use the specified power supply to connect. ■ Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers. ■ There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.

  • Page 3: Table Of Contents

    Table of Contents Introduction ........................1 IE Remote Access ......................2 LAN ........................2 2.1.1 Access through IP-Tool ................2 2.1.2 Directly Access through IE ............... 3 WAN ........................5 Remote Preview ......................8 The Remote Preview Interface ................8 Remote Live Surveillance ....................
  • Page 4 Network Camera User Manual Search ........................... 28 Appendix ..........................29 Appendix 1 Q & A ......................29 Appendix 2 Specifications ....................30...

  • Page 5: Introduction

    Network Camera User Manual 1 Introduction This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system more stable and reliable.

  • Page 6: Ie Remote Access

    Network Camera User Manual 2 IE Remote Access You may connect IP-Cam via LAN or WAN. Here only take IE browser (6.0) for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.

  • Page 7: Directly Access Through Ie

    Network Camera User Manual of your device according to the practical situation. For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please input the password of the administrator and click “Modify”...
  • Page 8 Network Camera User Manual Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable. ①...

  • Page 9: Wan

    Network Camera User Manual ② Open the IE browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control automatically. ③ After downloading Active X control, the login dialog box will pop up. ④...
  • Page 10 Network Camera User Manual ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and input its WAN IP and http port to access. ...
  • Page 11 Network Camera User Manual ① Go to ConfigNetwork Port menu to set the port number. ② Go to Config Network TCP/IPv4PPPoE Config menu. Check “Enable ” and then input the user name and password which you can get from your internet service provider. ③...

  • Page 12: Remote Preview

    Network Camera User Manual 3 Remote Preview 3.1 The Remote Preview Interface After you log in, you will see the following window. The following table is the instructions of the icons on the remote preview interface. Icon Description Icon Description Motion alarm indicator Start/stop live view icon...

  • Page 13: Remote Live Surveillance

    Network Camera User Manual 4 Remote Live Surveillance 4.1 System Configuration The “System Configuration” includes three submenus: Basic Information, Date & Time and Local Configuration. 4.1.1 Basic Information In the Basic Information interface, you can check the relative information of the device. 4.1.2 Date &...

  • Page 14: Local Configuration

    Network Camera User Manual 4.1.3 Local Configuration Go to ConfigSystemLocal Config. You can set the storage path of the captured pictures and video records. 4.2 Image Configuration Image Configuration includes five submenus: Display, Video/Audio, OSD, Video Mask and ROI Config. 4.2.1 Display Configuration Many parameters of the camera can be set in display configuration interface such as brightness, contrast, chroma, saturation wide dynamic, etc.

  • Page 15: Video Stream

    Network Camera User Manual Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Chroma: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color is, the brighter the image is. Wide Dynamic: It helps the camera provide clear images even under back light circumstances.

  • Page 16: Osd Configuration

    Network Camera User Manual resources are, the compression bitrate keeps constant. This will not only facilitate the image quality better in a constant bitrate but also help to calculate the capacity of the recording. VBR means that the compression bitrate can be adjustable according to the change of the video resources.

  • Page 17: Roi Configuration

    Network Camera User Manual To set up video mask 1. Open video mask. 2. Click “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to the live to see the following picture. Clear the video mask: Go to video mask menu and then click “Clear”...

  • Page 18: Alarm Configuration

    Network Camera User Manual 2. Check “Open” and then click “Draw Area” button. 3. Drag the mouse to set the ROI area. 4. Set the level. 5. Click “Save” button to save the settings. Now, you will see the selected ROI area is clearer than other areas especially in low bitrate condition.
  • Page 19 Network Camera User Manual Check “Enable Alarm” check box to activate motion based alarm, choose alarm holding time and set alarm trigger options. Trigger Email: If the email and attach picture checkbox is checked (Email address shall be set first in the Mail config interface), the triggered snap pictures and event will be sent into those addresses.

  • Page 20: Alarm Server

    Network Camera User Manual Week schedule Set the alarm time from Monday to Sunday for alarm everyday in one week. The lengthwise means one day of a week; the rank means 24 hours of a day. Green means selected area. Blank means unselected area.

  • Page 21: Network Configuration

    Network Camera User Manual 4.4 Network Configuration 4.4.1 TCP/IPv4 Go to ConfigNetworkTCP/IPv4. There are two ways for network connection.  Use IP address. There are two options for IP setup: obtain an IP address auto by DHCP protocol and use the following IP address. Please choose one of options for your requirements. ...

  • Page 22: Port

    Network Camera User Manual Trigger Email: when the IP address of the device is changed, a new IP address will be sent to the appointed mailbox automatically Trigger FTP: when the IP address of the device is changed, a new IP address will be sent to FTP server.
  • Page 23 Network Camera User Manual 2. Apply for a domain name. Take www. dvrdyndns.com for example. Input in the IE address bar to visit its website. Then click “Registration” button. www.dvrdydns.com Create domain name. After you successfully request your domain name, you will see your domain in the list.

  • Page 24: Snmp

    Network Camera User Manual 3. Input the username, password, domain you apply for in the DDNS configuration interface. 4. Click “Save” button to save the settings. 4.4.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, you can set the SNMP function.

  • Page 25: Rtsp

    Network Camera User Manual SNMPv3) according to the version of the SNMP software you download. 3. Set the “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port” and so on. Please make sure the settings are the same as that of your SNMP software. Note: Please use the different version in accordance with the security level you required.

  • Page 26: Ftp Setting

    Network Camera User Manual Sender Address: sender’s e-mail address; User name and password: sender’s user name and password; SMTP Address: The SMTP IP address or host name. Select the secure connection type at the Secure Connection pull down list according to user’ actual needs;...

  • Page 27: Security Configuration

    Network Camera User Manual To Add FTP Server Name：The name of the FTP. Server Address: The IP address or domain name of the FTP. Upload Path: The path of uploading the files. Port: The port of the FTP. Use Name and Password: The username and password are used to login the FTP. 4.5 Security Configuration 4.5.1 User Configuration Go to ConfigSecurity.
  • Page 28 Network Camera User Manual 2. Input user name in “User Name” textbox. 3. Input letters or numbers in “Password” and “Confirm Password” textbox. 4. Choose the use type. 5. Input the MAC address of the PC in “Binding MAC address” textbox. After binding physical address to the IP-CAM, you can access the device on this PC only.

  • Page 29: Online Video User

    Network Camera User Manual Note: The default super administrator cannot be deleted. 4.5.2 Online Video User Go to ConfigSecurityOnline Video User. You can view the user who is viewing the live video. 4.5.3 Block and Allow List Go to ConfigSecurityBlock and Allow Lists. Setting steps are as follows: Check “Enable IP address filtering”...

  • Page 30: Reboot Device

    Network Camera User Manual  Import & Export Setting: You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2. Click “Import Setting” or “Export Setting” button. ...

  • Page 31: Log

    Network Camera User Manual 4.6.4 Log To query and export log 1. Go to ConfigMaintenanceOperation Log. 2. Select the main type, sub type, start and end time. 3. Click “Query” to view the operation log. 4. Click “Export” to export the operation log. You can export and view the run log by clicking ConfigMaintenanceRun Log.

  • Page 32: Search

    Network Camera User Manual 5 Search You can play the local video record through search interface. Before playing, please set the storage path of the video record in the local configuration interface and make sure there are record files. After that, click “Search” tab on the menu toolbar. The following interface will be seen.

  • Page 33: Appendix

    Network Camera User Manual Appendix Appendix 1 Q & A Q: How to find my password if I forget it? A：Reset the device to the default factory settings. Default IP: 192.168.226.201 User name: admin Password: 123456 Q: Fail to connect devices through IE browser, why? A: Network is not well connected.

  • Page 34: Appendix 2 Specifications

    Network Camera User Manual ④ Then click OK to finish setup. b. Other plug-ins or anti-virus blocks ActiveX. Please uninstall or close them. Appendix 2 Specifications...
  • Page 35 Network Camera User Manual Specification /Model 20m IR Water-proof Bullet Network Camera 1/3＂CMOS Image Sensor 2048× 1536 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.07lux@F1.2, AGC ON; 0 lux with IR Min. llumination 3.6mm@F2.0, angle of view: 70° ; (2.8mm optional) Camera Lens Lens Mount...
  • Page 36 Network Camera User Manual Specification /Model 30m IR Water-proof Bullet Network Camera 1/3＂CMOS Image Sensor 2048× 1536 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.07lux@F1.2, AGC ON: 0 lux with IR Min. llumination 2.8~12mm@F1.4, Camera Lens angle of view: 84° ~27° Ø14 Lens Mount Day&Night...
  • Page 37 Network Camera User Manual Specification /Model 30m IR Water-proof 50m IR Water-proof Bullet Network Camera Bullet Network Camera 1/3＂CMOS Image Sensor 2048× 1536 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.07lux@F1.2, AGC ON: 0 lux with IR Min. llumination 6mm@F1.6, angle of view: 43°...
  • Page 38 Network Camera User Manual Specification /Model 20m IR Water-proof Dome Network Camera 1/3＂CMOS Image Sensor 2048× 1536 Image Size 1/25s~1/100000s Electronic Shutter Fixed Iris Auto Iris 0.07lux@F1.2, AGC ON: 0 lux with IR Min. llumination 3.6mm@F2.0, angle of view: 70° ; (2.8mm optional) Camera Lens Lens Mount...
  • Page 39 Network Camera User Manual...
