- Page 1 Operation Manual BTUR-303 3D Rotator Thank you for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.
-
Page 2: Table Of Contents
3D Rotator BTUR-303 Index 1. SAFETY FEATURES…………….…………………………..............03 2. PACKING ………………………..……………. ……….……..............03 3. STRUCTURE DESCRIPTION ……………….…….……..............05 4. TECHNICAL SPECIFICATIONS………….…. …………..............05 5. F1-F9 FIXED PROGRAM OPERATING INSTRUCTIONS …………………… ………………...09 6. PROGRAM DESCRIPTION……………………. …………...............11 7. CUSTOMIZATION PROGARM C1-C2……………………............13 8. C1,C2 CUSTOMIZATION MODE SETTING ……………............13... -
Page 3: Safety Features
Warranty Information We provide one-year warranty against any manufacturing fault. If BTUR-303 fails to function according to specifications at any time then please contact the manufacturer or local representative immediately. The warranty will not cover defects caused by normal wear or by a breach of the manufacture’s recommendations .Each BTUR-303 is tested before shipping by the manufacturer. - Page 4 3D Rotator BTUR-303 Rack model series Model Graphic Tube No. www.biolabscientific.com...
-
Page 5: Structure Description
3D Rotator BTUR-303 Structure Description HOST TUBE ADAPTER ROTATION SHAFT SPINDLES SLEEVE CONTROLL PANEL FIXING SCREW BASE PLATE Technical Specifications VARIABLE ROTATION SPEED REV/Min 1-99 SPEED SELECTION STEP REV/Min 1 ENVIRONMENTAL TEMPERATURE, □ +2-50 www.biolabscientific.com... - Page 6 3D Rotator BTUR-303 M SERIES RACK MODEL Model Graphic Tube No. www.biolabscientific.com...
- Page 7 3D Rotator BTUR-303 L SERIES RACK MODEL Model Graphic Tube No. RELATIVE MOISTURE OF THE ATMOSPHERE （AT THE TEMP, +20 ℃ ）： not more than 80% POWER ADAPTER INPUT ： 110V-220V/50-60Hz POWER ADAPTER OUTPUT ： 12VDC，1.5A POWER CONSUMPTION , W : no more than 12 www.biolabscientific.com...
-
Page 8: F1-F9 Fixed Program Operating Instructions
3D Rotator BTUR-303 MODEL DIMENSION WEIGHT (KG) (CM) BTUR-303 with BX-103945 316x125x168 BTUR-303 with BX-103944 344X125x168 BTUR-303 with BX-103943 420x125x168 F1-F9 Fixed Program Operating Instructions Press the power button 3 seconds and on/off the machine after plug into a power. - Page 9 3D Rotator BTUR-303 Press button for selecting “No rotation ”action 9. Press button for seventh stage setting Flashing on display press button for adjusting shaking time parameters ， 10. Press button for eighth stage setting Flashing on display press ，...
-
Page 10: Program Description
3D Rotator BTUR-303 Press button for selecting “clockwise rotation ”action Press button for adjusting rotation angle Operating mode showing. Shaking time and Operating time showing. Rotating angle and shaking frequency showing. Press this button the rack can be 180 ° rotating when the machine stopped for exchange tubes. - Page 11 3D Rotator BTUR-303 Variable shaking amplitude & rotation speed ; 135°clockwise rotation shaking 90° clockwise rotation, shaking; 135° clockwise rotation ;2 sec hold in initial point; the complete program can be timing. Variable shaking amplitude & rotation speed ; 135°Clockwise...
-
Page 12: C1,C2 Customization Mode Setting
3D Rotator BTUR-303 C1, C2 Customization Mode Setting The the required actions as below, 1. Counter clockwise rotation 170° 2.Shaking amplitude”3” 3. Clockwise rotation 90° 4. Pause time 8 sec 5. Counter clockwise rotation 80° 6. No need any actions 7. - Page 13 3D Rotator BTUR-303 2.Press button select ”clockwise rotation “,”counter clockwise rotation “, “ shaking ” , “pause ” “ No action” setting. Variable amplitude & speed ;110° clockwise rotation shaking ;110° counter clockwise rotation , Initial point 2sec shaking , 110°counter...
- Page 14 BIOLAB SCIENTIFIC LTD. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8 Canada Email: contact@biolabscientific.com Tel: +1 707 533 1445 Website: www.biolabscientific.com...
