Summary of Contents for BioLAB BIGP-502
- Page 1 Operation Manual BIGP-502 General Purpose Incubator Thank you for Choosing Biolab products. Please read the “Operating Instructions” and “Warranty” before operating this unit to assure proper operation.
-
Page 2: Table Of Contents
General Purpose Incubator BIGP-502 Index 1. The applicability................03 2. The technology parameters.............03 3. Properties and functions of the product...........04 4. Configuration and operating principle..........04 5. Operating method................05 6. Operating method to the intelligent temperature controller...06 7. Precautions and maintenance's............11 8. Trouble removal................12... -
Page 3: The Applicability
General Purpose Incubator BIGP-502 The applicability The new desk-style constant temperature incubator box, which integrated the company’s experience for many years, having the properties of high quality, reliability and safety, adopting the manner of air forcing convection with the blower fan, giving help to the scientific research and the production, and providing the most credible guarantees. -
Page 4: Properties And Functions Of The Product
General Purpose Incubator BIGP-502 Note: 1. The technology indexes are measured under the condition of 25°C, the relative humidity less than 85% and the constant temperature working; 2. The measuring temperature in door should adopt the mercury thermometer with ±1°C, and the mercury sensing temperature head should be place on the geometry center of the workshop. -
Page 5: Operating Method
General Purpose Incubator BIGP-502 installed on the left and back for the convenience of operating; when the temperature produces the signal of measuring the temperature (resistance value) and inputs into the controlling temperature instrument, comparing with the set signal value, and making the positive warp, then spring the controlled silicon to conduct, and the heating film is heated. -
Page 6: Operating Method To The Intelligent Temperature Controller
General Purpose Incubator BIGP-502 90min, the temperature controlling will come into the constant temperate state. D. When the required temperature is lower, the two times setting manner could be adopted, if the required temperature is 37°C, the first time, the 35°C could be set, and when temperature overshoot begin dropping, the second setting could be 37°C, which could reduce or stop the temperature overshoot, and come into the... - Page 7 General Purpose Incubator BIGP-502 1). PROG area: Showing program work group or setup group. 2). STEP area: Showing number of section in operation or parameter code 3). TIME area: Showing running time and parameter value. 4). PV area: Display measuring temperature.
- Page 8 General Purpose Incubator BIGP-502 key, PROG will blink, STEP will display 1, prompting what is revised is the parameter of Section 1 of the setup group. TIME area blinks, prompting revision of time; press plus or minus, shift key to adjust the setup time of Section 1 of the group;...
- Page 9 General Purpose Incubator BIGP-502 to an end automatically. A new group of PID parameter will be obtained and the controller will exercise control by the new PID parameters. In auto-tuner operation, pressing minus key for long will permit an exit from auto-tuner.
- Page 10 General Purpose Incubator BIGP-502 2）When LK shows up in the output area of LC screen，pressing plus or minus key to make LK=18，clicking and pressing SET key will permit entry to the user parameter stratum setup; Name Setting Description Facto range...
-
Page 11: Precautions And Maintenance's
General Purpose Incubator BIGP-502 reusing when not using for a long time, or the temperature changing in using, or the season changing. When the working temperature in the box is set at 37°C, if the temperature of the surrounds is over than 32 °C, the incubator should better be placed the indoor surroundings with air condition surrounding which makes the working temperature is under 32°C. -
Page 12: Trouble Removal
General Purpose Incubator BIGP-502 plastic anti air cover should be placed on the box, and place the incubator box in the dry room to avoid hurting the temperature controlling instruments for the humidity. Trouble removal Failure Reason for presuming The handing ways for... - Page 13 General Purpose Incubator BIGP-502 Displaying temperature > Reducing the RT setting temperature temperature, and modifying the “OUT-”, Displaying temperature < Increasing the “OUT-” Producing the static difference setting temperature Blower fun does not run Repairing it The sensor (Pt100) connects...
- Page 14 BIOLAB SCIENTIFIC LTD. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8 Canada Email: contact@biolabscientific.com Tel: +1 707 533 1445 Website: www.biolabscientific.com...
