DIGITAL PROPORTIONAL R/CSYSTEM
Fine adjustment switch:
The lower left trimming switch corresponds to channel 4, and the right trimming switch corresponds to
channel 1; Upper left fine adjustment switch, left modeCorresponds to channel 3, and the right arrow mode
corresponds to channel 2; Upper right fine adjustment switch, left mode corresponds to channel 2, right
modeEquation corresponds to channel 3; As shown in the following figure.
Left hand mode
Right hand mode
Mixed control:
After turning on the machine, press the (MIX) key for 3 seconds to switch to mixed control mode,The left light
of the mixed control light is on for 1/2 mixed control, and the right light is on for 2/4 mixed control,As shown in
the following figure, two lights off indicate no mixed control.
1/2hybrid control
3
2
4
2/4hybrid control
2.4GHz
Left hand mode
2
Right hand mode
3
1
www.microzone.cn
FHSS
Advertisement
Need help?
Do you have a question about the 6C-MINI and is the answer not in the manual?
Questions and answers
how do i conect to picasim on laptop with the 6c mini microzone
To connect the Microzone 6C-MINI to a flight simulator like Picasim on a laptop, follow these steps:
1. Get a 3.5mm Male-to-Male Audio Cable – Connect one end to the transmitter and the other to the microphone input on your PC.
2. Set the Transmitter to Mode 1 – Ensure the transmitter is in Mode 1 for standard control layout.
3. Download Required Software – Install SmartPropoPlus (a free tool that allows audio-based RC transmitter input) on your PC.
4. Install Picasim – Download and install the Picasim simulator.
5. Configure SmartPropoPlus – Open it and ensure it detects your transmitter’s input through the microphone port.
6. Calibrate Controls – In the simulator, calibrate the transmitter channels for correct stick movement.
This setup allows your Microzone 6C-MINI to act as a joystick input for the simulator.
