- Page 1 2.4GHz FHSS DIGITAL PROPORTIONAL R/CSYSTEM R850 PRODUCT MANUAL Please read the manual before use www.microzone.cn...
- Page 2 2.4GHz FHSS DIGITAL PROPORTIONAL R/CSYSTEM STANDARD RECEIVER FUNCTION ANALYSIS R850 Antennae Motor 2 Motor 1 DC+24V Input (connected to DC brush motor) (connected to DC brush motor) Cathode Anodal Cathode Anodal Cathode Anodal Anodal Anodal Cathode Cathode Anodal Anodal Cathode...
- Page 3 2.4GHz FHSS DIGITAL PROPORTIONAL R/CSYSTEM RECEIVER SPECIFICATIONS AND PARAMETERS Model R850 Color Ferrous Applications Lawn mower 2 PWM signals,1 external voltage input Channel output Control range >800m Frequency range 2401MHz-2478MHz Receiver power supply requirements DC:12-48V Voltage return Support PWM signal...
- Page 4 Power/signal transceiver lamps System operation light FM button Safe Shutdown Recommendation: To ensure the safety of your equipment and yourself, turn off the power to the equipment first and then to the remote control after the equipment motor has stopped running. www.microzone.cn...
-
Page 5: Matters Needing Attention
Read this guide and follow the instructions. 11. The remote control and receiver required for our company's 2.4G wireless transmission system are used in pairs, while other company products cannot be connected to our company's products The product is of great value. www.microzone.cn...
