Gesamtbedienungsanleitung
Für
LMRS_34*200 IO-LINK
Material Nr.
344-00028
Generiert am
12.07.2023
Enthält Originalbedienungsanleitung
Dokumentationsabschnitte
Betriebsanleitung
de/en LMP-30, LM_S-34 IO-Link
Konformitätserklärung de/en EU-Konformitätserklärung ELA (EMV+RoHS)
Konformitätserklärung de/en UKCA, Konformitätserkl. ELA (EMV+RoHS)
Technische Daten
Seite 1/1
TR-ELA-BA-DGB-0026-04.pdf
TR-ELA-KE-DGB-0079-02.pdf
TR-ELA-KE-GB-0080-02.pdf
Änderungen vorbehalten.
TR-Electronic GmbH
Eglishalde 6
78647 Trossingen
Tel. +49 (0) 7425 228-0
info@tr-electronic.de
www.tr-electronic.de
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TR-Electronic LMRS-34-200 IO-LINK
Summary of Contents for TR-Electronic LMRS-34-200 IO-LINK
- Page 1 Enthält Originalbedienungsanleitung Dokumentationsabschnitte Betriebsanleitung de/en LMP-30, LM_S-34 IO-Link TR-ELA-BA-DGB-0026-04.pdf Konformitätserklärung de/en EU-Konformitätserklärung ELA (EMV+RoHS) TR-ELA-KE-DGB-0079-02.pdf Konformitätserklärung de/en UKCA, Konformitätserkl. ELA (EMV+RoHS) TR-ELA-KE-GB-0080-02.pdf Technische Daten Änderungen vorbehalten. TR-Electronic GmbH Eglishalde 6 78647 Trossingen Tel. +49 (0) 7425 228-0 Seite 1/1 info@tr-electronic.de www.tr-electronic.de...
- Page 2 Seite 2 - 26 Page 27 -51 Linear Encoder magnetostriktiv Baureihen: - LMP-30 - LM_S-34 Explosionsschutzgehäuse _Zusätzliche Sicherheitshinweise _Installation _Inbetriebnahme _Parametrierung _Störungsbeseitigung und Diagnosemöglichkeiten Benutzerhandbuch Schnittstelle...
- Page 3 < > weist auf Tasten der Tastatur Ihres Computers hin (wie etwa <RETURN>). Marken ist ein eingetragenes Warenzeichen der IO-Link-Firmengemeinschaft TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 2 of 52 TR-ELA-BA-DGB-0026-04...
-
Page 4: Table Of Contents
8 System-Kommandos (Index 0x0002) ..................... 20 8.1 Set position – Funktion, Kommando 0xA0 ................20 8.2 Auslieferungszustand wiederherstellen – Funktion, Kommando 0x82 ........20 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04... - Page 5 9.4 ISDU-Fehlertypen ........................24 9.5 Prozessdaten - Status ......................25 9.6 Sonstige Störungen ........................ 25 10 Austauschen des Mess-Systems ....................26 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 4 of 52 TR-ELA-BA-DGB-0026-04...
-
Page 6: Änderungs-Index
- Common Profile integriert: Index 13 Profile Characteristic (0x4000) 23.07.2018 - Neue Funktionsklasse: 0x8100: Extended Identification LM_S-34 ergänzt 09.04.2019 Baureihen auf der Deckseite aufgenommen 26.01.2023 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 5 of 52... -
Page 7: Allgemeines
Es gelten somit zusammen folgende Dokumentationen: • siehe Kapitel „Mitgeltende Dokumente“ in der Montageanleitung www.tr-electronic.de/f/TR-ELA-BA-DGB-0004 • Produktdatenblätter: www.tr-electronic.de/s/S016638 • optional: -Benutzerhandbuch mit Montageanleitung TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 6 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 8: Referenzen
Bestätigung übertragen werden. PROFIBUS Nutzerorganisation e.V. Single-drop digital communication interface for small sensors and SDCI actuators TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 7 of 52... -
Page 9: Zusätzliche Sicherheitshinweise
Master nach der IO-Link Interface und System Spezifikation, Version 1.1 der IO-Link- Firmengemeinschaft. Die technischen Richtlinien zum Aufbau des IO-Link Netzwerks der PROFIBUS Nutzerorganisation (PNO) sind für einen sicheren Betrieb zwingend einzuhalten. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 8 of 52 TR-ELA-BA-DGB-0026-04... -
Page 10: Einsatz In Explosionsfähigen Atmosphären
Eigenschaften den applikationsspezifischen Anforderungen genügen. Der gefahrlose Einsatz erfordert zusätzliche Maßnahmen bzw. Anforderungen. Diese sind vor der Erstinbetriebnahme zu erfassen und müssen entsprechend umgesetzt werden. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04... -
Page 11: Io-Link Informationen
Tel.: ++ 49 (0) 721 / 96 58 590 Fax: ++ 49 (0) 721 / 96 58 589 e-mail: mailto:info@io-link.com TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 10 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 12: Installation
- IEC 60947-5-2, Niederspannungsschaltgeräte - EMV-Richtlinie ● Es wird empfohlen, nach Abschluss der Montagearbeiten eine visuelle Abnahme mit Protokoll zu erstellen. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 11 of 52... -
Page 13: Io-Link
Das Mess-System belegt über die zyklischen Daten insgesamt 6 Bytes Eingangsdaten und 0 Byte Ausgangsdaten. Prozessdaten-Struktur: 4-Bytes Positionsdaten 2-Bytes Geschwindigkeitsdaten OUT: 0-Bytes TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 12 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 14: Anschluss
Definiert und standardisiert den internen Geräte-Aufbau (Geräte-Modell) und enthält folgende Funktionsklassen: 0x8000: Device Identification 0x8002: ProcessDataVariable 0x8003: Diagnosis 0x8100: Extended Identification TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 13 of 52... -
Page 15: Inbetriebnahme
Firmenkennung, der VendorID, und einem herstellerspezifischen Teil, der DeviceID. Die VendorID wird von der PNO vergeben und hat für die Firma TR-Electronic den Wert 0x0153, die DeviceID ist gerätespezifisch. Im Hochlauf wird die projektierte Geräteidentifikation überprüft und somit Fehler in der Projektierung erkannt. -
Page 16: Prozess-Eingangsdaten
Die Geschwindigkeit wird in mm/s ausgegeben, siehe Parameter „Index 0x0047: Velocity unit“ auf Seite 18. über- Wird Wertebereich Geschwindigkeit (-32768…+32767) oder unterschritten, werden die Grenzwerte (0x7FFF bzw. 0x8000) ausgegeben. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 15 of 52... -
Page 17: Parametrierung
Wert (StringT) Zugriff ‘***’ 0x0018 Application Specific Tag StringT32 ‘***’ 0x0019 Function Tag (UTF-8) StringT32 ‘***’ 0x001A Location Tag (UTF-8) StringT32 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 16 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 18: Geräteparameter
(Index 0x0041, Measuring length of encoder) ergibt sich die Gesamtschrittzahl über den gesamten Messbereich des Mess-Systems. Messlänge Messlänge Schritten Auflösung TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 17 of 52... -
Page 19: Index 0X0045: Filter
Wert Zuordnung Beschreibung Default 0x0001 velocity in 0,1mm/s Ausgabe in 0,1 mm/s 0x000A velocity in mm/s Ausgabe in 1,0 mm/s TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 18 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 20: Index 0X0048: Operating Time
Die Betriebsdauer wird in 0,1 Std. pro Digit erfasst. Index Subindex Name Länge Zugriff 0x0048 Operating time 32 Bit UIntegerT TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 19 of 52... -
Page 21: System-Kommandos (Index 0X0002)
0x0020), Gerätestatus (Index 0x0024) und Ausführlicher Gerätestatus (Index 0x0025) zurückgesetzt. Index Subindex Name Länge Zugriff System-Command 0x0002 8 Bit UIntegerT Kommando-Code = 0x82 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 20 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 22: Störungsbeseitigung Und Diagnosemöglichkeiten
Prozessdaten gültig -> WARNUNG - EVENT 0x03 wird nicht unterstützt Fehler aufgetreten, 0x04 Prozessdaten ungültig -> FEHLER - EVENT 0x05...0xFF reserviert TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 21 of 52... -
Page 23: Ausführlicher Gerätestatus (Index 0X0025)
- 0x02: Warnung vorhanden - 0x03: Fehler vorhanden Mode, Bit 6...7 - 0x02: Event disappears (Ereignis verschwunden) - 0x03: Event appears (Ereignis aufgetreten) TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 22 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... - Page 24 (Index 0x0024) Prozess-Variablen-Be- Linearitätsgrenzen über- reich unterschritten – schreiten. Prozessdaten unsicher -> Magnet in den zulässigen Messbereich bewegen W: WARNUNG FEHLER TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 23 of 52...
-
Page 25: Isdu-Fehlertypen
- Service wiederholen - Gerät AUS/EIN - Vollständige Initialisierung abwarten 0x80 0x82 Applikation noch beschäftigt - Service wiederholen - Gerät AUS/EIN TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 24 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 26: Prozessdaten - Status
Kabel elektrische Störungen (EMV) paarweise verdrillten Adern für Daten und Versorgung. Siehe auch Vorgaben unter Kapitel „Installation“ ab Seite 11. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 25 of 52... -
Page 27: Austauschen Des Mess-Systems
Positionswertes ist gemäß Kap. 8.1 auf Seite 20 vorzunehmen. Bei der Wiederinbetriebnahme des ausgetauschten Mess-Systems sollte die richtige Funktion zuerst durch einen abgesicherten Testlauf sichergestellt werden. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 26 of 52... - Page 28 - LMP-30 - LM_S-34 Explosion Protection Enclosure _Additional safety instructions _Installation _Commissioning User Manual _Parameterization Interface _Troubleshooting / Diagnostic options TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 27 of 52...
- Page 29 > indicates keys on your computer keyboard (such as <RETURN>). Brand names is a registered trademark of the IO-Link Community TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 28 of 52 TR-ELA-BA-DGB-0026-04...
-
Page 30: Contents
8 System commands (Index 0x0002) ....................46 8.1 Set position – function, command 0xA0 ................. 46 8.2 Restore factory settings – function, command 0x82............... 46 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023... - Page 31 9.4 ISDU error types ........................50 9.5 Process data - status ......................51 9.6 Other faults ..........................51 10 Replacing the measuring system ....................52 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 30 of 52 TR-ELA-BA-DGB-0026-04...
-
Page 32: Revision Index
- Common Profile integrated: Index 13 Profile Characteristic (0x4000) 07/23/2018 - New Function Class: 0x8100: Extended Identification LM_S-34 added 04/09/2019 Series included on the deck side 01/26/2023 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 31 of 52... -
Page 33: General Information
“Other applicable documents” in the Assembly Instructions www.tr-electronic.com/f/TR-ELA-BA-DGB-0004 • Product data sheets www.tr-electronic.com/s/S016648 • optional: -User Manual with assembly instructions TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 32 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 34: References
ISDU transmission of parameters. PROFIBUS User Organization (PROFIBUS Nutzerorganisation e.V.) Single-drop digital communication interface for small sensors and SDCI actuators TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 33 of 52... -
Page 35: Additional Safety Instructions
The technical guidelines for the structure of the IO-Link network of the PROFIBUS User Organization (PNO) are always to be observed in order to ensure safe operation. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany... -
Page 36: Usage In Explosive Atmospheres
Fail-safe usage requires additional measures and requirements. Such measures and requirements must be determined prior to initial commissioning and must be taken and met accordingly. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023... -
Page 37: Io-Link Information
Tel.: ++ 49 (0) 721 / 96 58 590 Fax: ++ 49 (0) 721 / 96 58 589 e-mail: mailto:info@io-link.com TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 36 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 38: Installation
- IEC 60947-5-2, Low-voltage switchgear and controlgear - EMC directive ● Upon completion of installation, a visual inspection with report should be carried out. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 37 of 52... -
Page 39: Io-Link
0 bytes output data. Structure of the process data: 4 bytes position data 2 bytes velocity data OUT: 0 bytes TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 38 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 40: Connection
Define and standardize the internal device set up (device model) and contain the following function classes: 0x8000: Device Identification 0x8002: ProcessDataVariable 0x8003: Diagnosis 0x8100: Extended Identification TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 39 of 52... -
Page 41: Commissioning
Each IO-Link device possesses a device identification. It consists of a firm identification, the VendorID, and a manufacturer-specific part, the DeviceID. The VendorID is assigned by the PNO. For TR-Electronic the VendorID contains the value 0x0153, the DeviceID is device specific. -
Page 42: Process Input Data
The velocity is output in mm/s, see parameter “Index 0x0047: Velocity unit” on page 44. If the velocity exceeds the value range of –32768…+32767, the limit values (0x7FFFor 0x8000) are output. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023... -
Page 43: Parameterization
Type Access ‘***’ 0x0018 Application Specific Tag StringT32 ‘***’ 0x0019 Function Tag (UTF-8) StringT32 ‘***’ 0x001A Location Tag (UTF-8) StringT32 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 42 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 44: Device Parameters
(index 0x0041, Measuring length of encoder) results in the total number of steps over the entire measuring range of the measuring system. Measuring length [mm] Measuring length in steps = Resolution [mm] TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 43 of 52... -
Page 45: Index 0X0045: Filter
Value Assignment Description Default 0x0001 velocity in 0.1mm/s output in 0.1 mm/s 0x000A velocity in mm/s output in 1.0 mm/s TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 44 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 46: Index 0X0048: Operating Time
The value is given in 0.1 hours per digit. Index Subindex Name Length Type Access 0x0048 Operating time 32 Bit UIntegerT TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 45 of 52... -
Page 47: System Commands (Index 0X0002)
Device status (Index 0x0024) and Detailed device status (Index 0x0025) are reset. Index Subindex Name Length Type Access System-Command 0x0002 8 Bit UIntegerT Command code = 0x82 TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 46 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 48: Troubleshooting And Diagnosis Options
-> WARNING - EVENT 0x03 Not supported Failure occurred, 0x04 process data invalid -> ERROR - EVENT 0x05...0xFF Reserved TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 47 of 52... -
Page 49: Detailed Device Status (Index 0X0025)
Type, Bit 4...5 - 0x02: Warning present - 0x03: Error present Mode, Bit 6...7 - 0x02: Event disappears - 0x03: Event appears TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 48 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... - Page 50 (Index 0x0024) uncertain sheet. -> Move magnet into the permissible measuring range W: WARNING ERROR TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04 Page 49 of 52...
-
Page 51: Isdu Error Types
- Device OFF/ON - Await complete initialization (start-up phase) 0x80 0x82 Application not ready - Repeat service - Device OFF/ON TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany Page 50 of 52 TR-ELA-BA-DGB-0026-04 01/26/2023... -
Page 52: Process Data - Status
Electrical faults (EMC) as shielded cables with twisted pair wires for data and supply. Also see guidelines in chapter “Installation” as from page 37. TR-Electronic GmbH 2017, All Rights Reserved Printed in the Federal Republic of Germany 01/26/2023 TR-ELA-BA-DGB-0026-04... -
Page 53: Replacing The Measuring System
Here, the user must check whether this data saving is suitable for the replacement. The new measuring system should have the same article number as the measuring system being replaced; any deviations should be clarified with TR-Electronic. Depending on the application, the output position value must possibly be adjusted to the reference position of the machine. - Page 54 Elektro- und Elektronikgeräten (RoHS) 2011/65/EU (L 174/88) Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) in alleiniger Verantwortung von / under the sole responsibility of: TR-Electronic GmbH Eglishalde 6 D - 78647 Trossingen Tel.: 07425/228-0...
- Page 55 Gültigkeitsliste / List of validity Baureihe / Series: LMRB 27 Order No.: 341-xxxxx, 343-xxxxx Type: LMRB-27 Baureihe / Series: LMP 30 Order No.: 322-xxxxx Type: LMP-30 Baureihe / Series: LMRS 34 Order No.: 344-xxxxx Type: LMRS-34 Baureihe / Series: LMPS 34 Order No.: 345-xxxxx Type: LMPS-34...
- Page 56 Baureihe / Series: LP 46 Order No.: 320-xxxxx Type: LP-46, LP-46K Baureihe / Series: LMRI 46 Order No.: 339-xxxxx Type: LMRI-46 Baureihe / Series: LMPI 46 Order No.: 340-xxxxx Type: LMPI-46 Baureihe / Series: LA 47 Order No.: 328-xxxxx, 338-xxxxx Type: LA-47 Baureihe / Series: LMR 48...
- Page 57 Baureihe / Series: LA 66 Order No.: 312-xxxxx Type: LA-66, LA-66K Baureihe / Series: LMR 70 Order No.: 335-xxxxx Type: LMR-70 Baureihe / Series: LA 80 Order No.: 314-xxxxx Type: LA-80 Baureihe / Series: LAK01 Order No.: 315-xxxxx Type: LAK01 TR-ELA-KE-DGB-0079-02.docx 4 / 4...
- Page 58 The Restriction of the Use of Certain Hazardous Substances in S.I. 2012 No. 3032 Electrical and Electronic Equipment Regulations 2012 under the sole responsibility of the manufacturer: Name and address of authorised representative: TR-Electronic GmbH TR-Electronic Ltd. Eglishalde 6 4 William House D - 78647 Trossingen Old St.
- Page 59 List of validity Series: LMRB 27 Order No.: 341-xxxxx, 343-xxxxx Type: LMRB-27 Series: LMP 30 Order No.: 322-xxxxx Type: LMP-30 Series: LMRS 34 Order No.: 344-xxxxx Type: LMRS-34 Series: LMPS 34 Order No.: 345-xxxxx Type: LMPS-34 Series: LP 38 Order No.: 307-xxxxx Type: LP-38 Series: LA 41...
- Page 60 Series: LP 46 Order No.: 320-xxxxx Type: LP-46, LP-46K Series: LMRI 46 Order No.: 339-xxxxx Type: LMRI-46 Series: LMPI 46 Order No.: 340-xxxxx Type: LMPI-46 Series: LA 47 Order No.: 328-xxxxx, 338-xxxxx Type: LA-47 Series: LMR 48 Order No.: 327-xxxxx Type: LMR-48 Series: LMP 48...
- Page 61 Series: LA 66 Order No.: 312-xxxxx Type: LA-66, LA-66K Series: LMR 70 Order No.: 335-xxxxx Type: LMR-70 Series: LA 80 Order No.: 314-xxxxx Type: LA-80 Series: LAK01 Order No.: 315-xxxxx Type: LAK01 TR-ELA-KE-GB-0080-02.docx 4 / 4...
- Page 62 SCHNITTSTELLE IO-Link VERSORGUNGSSPANNUNG 24V+/-20% ANSCHLUSSART 1X4P.M12-STECKER ANSCHLUSSRICHTUNG AXIAL GEGENSTECKER NEIN STABLAENGE 287,00 mm STABSPITZENLAGERUNG NEIN FLANSCHTYP STAHLFLANSCH ABGEPRESST MAGNET-TYP OHNE MAGNET ARBEITSTEMPERATUR -40+80°C Änderungen vorbehalten. TR-Electronic GmbH Eglishalde 6 78647 Trossingen Tel. +49 (0) 7425 228-0 Seite 1/3 info@tr-electronic.de www.tr-electronic.de...
- Page 63 - IO-Link Spezifikation V1.1 - Prozessdaten-Eingang 4-Bytes Positionsdaten - Prozessdaten-Eingang 2-Bytes Geschwindigkeitsdaten - Zykluszeit >= 1 ms Übertragungsrate - Kennwert COM 3: 230,4 kbit/s Änderungen vorbehalten. TR-Electronic GmbH Eglishalde 6 78647 Trossingen Tel. +49 (0) 7425 228-0 Seite 2/3 info@tr-electronic.de www.tr-electronic.de...
- Page 64 Relative Luftfeuchte 98 %, keine Betauung Schutzart - Standard IP67 Druckfestigkeit - Statisch PN = 400 bar - Spitze Pmax = 450 bar Änderungen vorbehalten. TR-Electronic GmbH Eglishalde 6 78647 Trossingen Tel. +49 (0) 7425 228-0 Seite 3/3 info@tr-electronic.de www.tr-electronic.de...
