- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Interactive Whiteboard Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description WBM2...
-
Page 2: Installation Instructions
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the WBM2 does not exceed 125 lbs (56.7 kg). - Page 3 Installation Instructions WBM2 DIMENSIONS 1192.1 46.93 DIMENSIONS: [MILLIMETERS] INCHES...
- Page 4 WBM2 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions WBM2 TOOLS REQUIRED FOR INSTALLATION 1/8" - wood stud 1/4" - concrete, brick 7/16" PARTS B (4) [Toggler] F (2) E (1) 1/4-20 x 3/8" 5/32" A (4) 1/4" G (4) [Isolation washer] C (4) 1/4-20 x 2-1/2"... -
Page 6: Assembly And Installation
(A) to attach wall assembly (K) to wall. (See Figure 2) the weight of the WBM2 and all attached equipment not to exceed 125 lbs (56.7 kg). Mark the wall through the lower mounting hole in the wall assembly (K). - Page 7 Installation Instructions WBM2 Using a level, mark the wall above existing chalkboard through top mounting hole in the wall assembly (K). (See (D) x 2 Interactive Figure 3) white board (B) x 4 (G) x 4 (J) x 4 (A) x 4...
- Page 8 WBM2 Installation Instructions Adjustments Tighten four Phillips head screws (H) into four isolation washers (G) and spacers (J) to fasten white board to upright Lateral Movement assembly (D). (See Figure 8) Loosen one button head cap screw at top of upright assembly (D).
-
Page 9: Adding Covers
Installation Instructions WBM2 Adding Covers Open the lower flaps of the wall bracket cover (L) outward. (See Figure 10) Slide the cover downward, hooking the top of the wall bracket covers (L) onto the tabs on top of wall assembly brackets. - Page 10 WBM2 Installation Instructions...
- Page 11 Installation Instructions WBM2...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
