- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Universal Interactive Board Adapter Kit Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description WBAU...
-
Page 2: Important Safety Instructions
Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to the WBAU does not exceed 125 lbs (56.7 kg). WARNING: Use this mounting system only for its intended use as described in these instructions. - Page 3 Installation Instructions WBAU DIMENSIONS 46.00 1168.4 DIMENSIONS: INCHES [MILLIMETERS] LEGEND Tighten Fastener Open-Ended Wrench Apretar elemento de fijación Llave de boca Befestigungsteil festziehen Gabelschlüssel Apertar fixador Chave de bocas Serrare il fissaggio Chiave a punte aperte Bevestiging vastdraaien Steeksleutel Serrez les fixations Clé...
-
Page 4: Tools Required For Installation
WBAU Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/2" 5/32" (included) 1/2" PARTS A (4) [Hook bracket] B (4) [Vertical bracket] E (8) 5/16" C (8) 1/4-20 x 1/2" F (1) 5/32" D (8) 1/4"... -
Page 5: Assembly And Installation
Installation Instructions WBAU ASSEMBLY AND INSTALLATION WBM2 upright Assembly Assemble one hook bracket (A) to one vertical bracket (B) using two 1/4-20 x 1/2" button head cap screws (C) and two 1/4" flat washers (D). (See Figure 1) Repeat for remaining three bracket assemblies. - Page 6 Installation Instructions IMPORTANT ! : Loosen button head cap screws (C) on bracket assemblies The WBAU accessory is compatible with using 5/32" hex head wrench (F) to allow adjustment to fit boards 26.69" (minimum) - 59.22" (maximum) tall, and 0.51"...
- Page 7 Installation Instructions WBAU...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
