Summary of Contents for CHIEF WBM3E
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Telescoping Leg Interactive Whiteboard Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description WBM3E...
-
Page 2: Installation Instructions
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the WBM3E does not exceed 125 lbs (56.7 kg). - Page 3 Installation Instructions WBM3E DIMENSIONS 46.93 1192.0 MACRO ADJUSTMENT FULLY RETRACTED FULLY EXTENDED DIMENSIONS: [MILLIMETERS] INCHES...
- Page 4 WBM3E Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions WBM3E TOOLS REQUIRED FOR INSTALLATION 7/16" 1/8" - wood stud 1/2" 1/4" - concrete, brick 5/32" 1/2" (included) PARTS B (4) F (2) [AF6 Toggler] 1/4-20 x 3/8” D (2) E (1) A (4) [Upright assembly] 5/32” 1/4”... -
Page 6: Assembly And Installation
OR DAMAGE TO EQUIPMENT! It is the installers responsibility to make certain the structure to which the mount is being attached is capable of supporting five times the weight of the WBM3E and all attached equipment not to exceed 125 lbs (56.7 kg). (T) x 3... -
Page 7: Installing To A Wood Stud Wall
(C) x 4 Figure 4 Installing to a Concrete or Concrete Block Wall NOTE: The WBM3E may be attached to an 8" concrete wall or an 8" x 8" x 16" concrete block wall. Determine the center of the chalkboard. NOTE:... - Page 8 WBM3E Installation Instructions Drill one 1/4” x 2-3/4” pilot hole at each marking. (See Figure assembly (K). (See Figure 7) Move the slide nut so that it is aligned with the upright (D). Install a Toggler (B) into each pilot hole using a hammer.
- Page 9 Tighten four Phillips head screws (H) into four isolation • If the WBM3E has been installed with the alternate foot (P) attached, proceed to Adding Covers washers (G) and spacers (J) to fasten white board to upright section to complete installation.
- Page 10 BEFORE completing attachment to wall. Drywall NOTE: The lower part of the WBM3E must be attached to the Plastic Straps wall using the correct hardware for the wall type. It may be attached to a wood stud wall or a concrete or concrete block wall.
-
Page 11: Adding Covers
Installation Instructions WBM3E Use two 1/4-20 x 1 3/4” Phillips pan machine screws (Z) and Adding Covers two 1/4” flat washers (U) to attach both adjustable legs (N) to Open the lower flaps of the wall bracket cover (L) outward. - Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 1 on 12/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
