Cheval - 4 Drawer Chest
Assembly Instructions -
Dimensions
Width - 71cm
Depth - 36cm
Height - 73cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
258/7260
268/9254
274/9981
275/2514
MADE IN
BRITAIN
Issue 1 - 13/06/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Cheval 258/7260
Summary of Contents for Argos Cheval 258/7260
- Page 1 Cheval - 4 Drawer Chest Assembly Instructions - 258/7260 Please keep for future reference 268/9254 274/9981 275/2514 Dimensions Width - 71cm Depth - 36cm MADE IN Height - 73cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 13/06/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 22kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2966A) (D2967A) (D2751A) (720 x 318mm) (720 x 318mm) (710 x 360mm) Rail...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 4 large drawer fronts Screw 2 metal dowels into each of the large drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the large drawer bases Slide the large drawer base down the grooves in the drawer sides down into the groove in the large drawer front Step 5 Fit the large drawer back Fit the large drawer back between the drawer sides Make sure that the large...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place 4 runners the left side shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place 4 runners the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and Finished fit the 2nd screw into...
- Page 9 Assembly Instructions Step 10 Prepare the 2 rails Tap 2 wooden dowels into each rail 10mm Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 2 large locking nuts into each rail Step 11...
- Page 10 Assembly Instructions Step 13 Prepare the top Screw 4 metal dowels into the top Fix the bracket in the centre of the top flush to the back edge, using screw Finished front edge Step 14 Fit the top Push the top onto the sides Use a screwdriver to...
- Page 11 Assembly Instructions Step 15 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3065...
