INSTALLATION INSTRUCTIONS

DISPENSER MODEL
ED200/250
Item No.
Part No.
1
629080214
2
29677
3
620023904
4
32990
5
50904
6
620013301
7
620500201
8
620914101
9
70555
10
71010
11
91486
!
WARNING:
Disconnect power to the unit before servicing. Follow all lock out/tag out procedures established by the user. Verify all
power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
1. Remove lower panel assembly from both Units.
2. Relocate beverage valve key switch to right side of the beverage panel on one of the Units. This Unit will be
positioned on the right side of the counter.
A. Remove beverage panel access covers.
B. Locate black and red wires of the key switch. Cut these wires approximately 2 inches from the crimp
nut connection to the yellow wires.
C. Loosen the key switch mounting nut and remove the key switch.
access the nut.
D. Remove plastic plug from right side of the beverage panel and insert into the left side key switch opening.
E. Install key switch into the right side of the beverage panel and tighten mounting nut.
F.
Move black and red wires from left to right side of the beverage panel. Strip red/black wires and recon-
nect to the key switch using wire connectors (item 4) provided.
G. Install beverage panel access covers.
3. Install Adaptor Kits if applicable for the type of ice makers used.
4. Apply self–adhesive gasket material (item 7) to the side of one Unit as indicated in Figure 1. Ends of the
gasket should fit tight to each other.
5. Place Units into position on the counter. The Units must be at the same height and sitting level. The out-
side-outside dimension of the Units should be 60-3/8 inches (3/8-inch between the Units at the center).
6. Remove one screw from each base at the rear of the Unit and install rear mounting plate (item 2) to main-
tain the proper spacing between the Units (see Figure 2).
Release Date: September 28, 2010
© 1998-2010, IMI Cornelius Inc.
ED2XX D
FOR
Table 1. Parts List
Insulated Lower Panel, Dual
Rear Mounting Plate
Front Mounting Plate (For 6 and 8 Beverage Valve Units)
Wire Connectors
RTV Sealant, 3-oz Tube
Drip Tray Cover, Black
Gasket
Installation Instructions
Screw, No. 8–32 By 1 5/16–In. long
Captivating Plastic Washer, No. 8
Cornelius Logo
www.cornelius.com
ED2XX Dual Mounting Kit Installation Manual
–M
K
UAL
OUNTING
KIT PART NUMBER
629085101
Name
Using a 7/8–inch deep socket will help
- 1 -
IT
Revision: B
Publication Number: 620914101
Qty.
1
1
1
4
2
1
150–In
1
2
2
1
