Cornelius Remcor C106 Installation Instructions

INSTALLATION INSTRUCTIONS

F ED250 D
OR
Item No. Part No.
1 22127
2 50904
3 70226
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
1. Seal the ice maker to the top of the dispenser as follows (see Figure 1).
A. Locate the outline of the ice maker on the dispenser lid as shown in Figure 1.
B. Run a bead of RTV inside the perimeter of the ice maker outline on the dispenser lid so that the ice
maker sets on the RTV.
C. Set the ice maker onto the lid and position it as shown in Figure 1.
D. Wipe away the excess RTV.
2. Drill 0.136" diameter holes (#29 drill) into the ice maker cabinet and the dispenser lid using the ice maker mount-
ing brackets as templates. Use extreme caution not to drill into any ice maker components (condenser, tubing,
etc.). Secure the brackets using the #10 sheet metal screws, 8 provided.
3. Follow the ice maker manufacturer's instructions to complete the installation of the ice maker including the bin
thermostat if so equipped or required.
!
CAUTION:
The bin thermostat location must not interfere with agitator rotation.
4. Secure the manual fill cover in position on the lid over the rear bin access opening with the thumbscrew. Note that
the insulation strip should be compressed against the ice maker cabinet to form a seal with the cover secured in
position.
Release Date: November 5, 2010
© 1997-2010, IMI Cornelius Inc.
/I -O-M
ISPENSER CE
Table 1. Loose Shipped Parts
Bracket, Ice Maker Mounting
RTV, 3OZ. Tube
#10 Sheet Metal Screw
www.cornelius.com
ED250 Dispenser/Ice-O-Matic Kit Installation Instructions
M C106 I
ATIC ODEL
Name
- 1 -
M
CE AKER
Qty.
2
1
8
Revision: B
Publication Number: 620906801
