Step 3
H A R D WA R E
D
Plastic Dowel Ø8 x 32 mm
Screw M 6 x 8 mm
G
J
Drawer Runner
C O M P O N E N T S
7
Bottom Center Board
8
Left Self Board
12
Right Self Board
Step 4
H A R D WA R E
B
Cam Bolt Ø7.5 x 32 mm
D
Plastic Dowel Ø8 x 32 mm
C O M P O N E N T S
9
Side Left Self Support
10
Front Left Self Support
11
Back Left Self Support
13
Side Right Self Support
14
Front Right Self Support
15
Back Right Self Support
x14
x4
x1
x1
x1
x1
x8
x8
x1
x1
x1
x2
x1
x2
