modway EEI-6279 Assembly Instructions Manual page 10

Step 12
H A R D WA R E
A Cam Lock Ø15 mm
Cam Cover Ø17 mm
C
F Screw M 10 x 33.5 mm
C O M P O N E N T S
3
Left Side Board
4
Right Side Board
Step 13
H A R D WA R E
A Cam Lock Ø15 mm
Cam Cover Ø17 mm
C
C O M P O N E N T S
5
Middle Board
7
Bottom Center Board
x2
x2
x4
x1
x1
x2
x2
x1
x1
A
A
PAGE 10 OF 19
