ST STM32F746NGH6 Manual page 9

3V3
R116
10K_1%_0402
5V
R117
OTG_FS_PowerSwitchOn
0_5%_0402
5V_USB_FS
SB18
OTG_FS_VBUS
OTG_FS_N
OTG_FS_P
R133 0
OTG_FS_ID
3V3
R137
620_1%_0603
R126
47K_1%_0402
LD6
LED, red
U16
2 3
GND FAULT
5 1
IN OUT
4
EN
STMPS2141STR C112
4.7uF_X5R_10%_0603
R132 0 USB_FS1_N
R125 0 USB_FS1_P
U18
B3 A3
Vbus ID
C3 C1
D+out D+in
D3 D1
D-out D-in
A2 B1
Dz Pd1
B2 C2
Pup Pd2
D2
GND
EMIF02-USB03F2
R119
OTG_FS_OverCurrent
0_5%_0402
CN13
1
VBUS
2
DM
3
DP
4
ID
5
GND
6
Shield
USB-MICRO-AB
3V3
R136
330_1%_0603
LD5
LED, green
R134
47K_1%_0402
T2
1
9013-SOT23
R135
100K
Title: USB OTG FS with Micro A-B connector
Project: STM32F746G-DISCO
Variant: F746NGH6
Revision: C 01 - Reference: MB1191
Size: A4 Date: 17/07/2019 Sheet: 9 of 14
