TIG welding
5.1.8.6
TIG up/down torch (8-pole)
Up/down torch with one torch trigger
Figure
Functions
Welding current on/off
Secondary current (tapping function)
Increase welding current (up function
Decrease welding current (down function
Welding current on/off
Secondary current (tapping function)
Increase welding current via current jump
Decrease welding current via current jump
1
> see 5.1.8.1 chapter
2
> see 5.1.8.3 chapter
3
> see 5.1.8.4 chapter
30
Operating ele-
Explanation of symbols
ments
BRT 1 = torch trigger 1
)/(latched operating mode)
1
2
)
)
2
)/(latched operating mode)
1
3
3
Operating ele-
Mode
ments
1
(ex works)
4
