Tig Up/Down Torch (8-Pole) - EWM T4.02 Operating Instructions Manual

Functional characteristics
TIG welding

5.1.10.6 TIG up/down torch (8-pole)

Up/down torch with one torch trigger
Figure
Functions
Welding current on/off
Secondary current (tapping function)
Increase welding current (up function
Decrease welding current (down function
Welding current on/off
Secondary current (tapping function)
Increase welding current via current jump
Decrease welding current via current jump
1
> see 5.1.10.1 chapter
2
> see 5.1.10.3 chapter
3
> see 5.1.10.4 chapter
36
Operating ele-
Explanation of symbols
ments
BRT 1 = torch trigger 1
)/(latched operating mode)
1
2 )
)
2
)/(latched operating mode)
1
3
3
Operating ele-
Mode
ments
1
(ex works)
4
