For your safety

Part of the complete documentation

Symbol Description
Output
Time representation (e.g.: wait 4 s /
actuate)
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use
2.3 Part of the complete documentation
This document is part of the complete documentation and valid only in combination with all other
parts of these instructions! Read and observe the operating instructions for all system
components, especially the safety instructions!
The illustration shows a general example of a welding system.
Item Documentation
A.1 Options conversion instructions
A.2 Power source
A.3 Cooling unit, voltage converter, tool box etc.
A.4 Transport cart
A.5 Welding torch
A.6 Remote control
A.7 Control
A Complete documentation
6
Symbol Description
Signal light lights up in red
Signal light flashes red
Figure 2-1
099-00T406-EW501
14.07.2020
