Specifications - Avtech AVPP-2A-B Instructions Manual

Model :
1
Amplitude 2 : (50Ω load)
Pulse width (FWHM):
PRF:
Maximum duty cycle:
Rise times (20%-80%) 7 :
Fall times (80%-20%) 7 :
GPIB & RS-232 control 1 :
Required load impedance:
Polarity 3 :
LabView Drivers:
Ethernet port, for remote
control using VXI-11.3, ssh,
telnet, & web:
Calibration:
DC offset:
Propagation delay:
Jitter:
Trigger modes:
Variable delay:
Sync output:
Monitor output option 5 :
Connectors:
Optional accessory kit:
(attenuators and
terminators)
Optional accessory kit:
(coaxial cables and
adapters)
Power requirements:
Dimensions (H x W x D):
Chassis material:
Temperature range:
1) -B suffix indicates IEEE-488.2 GPIB and RS-232 control of amplitude, pulse width, PRF and delay (See http://www.avtechpulse.com/gpib/).
2) For operation at amplitudes of less than 20% of full-scale, best results will be obtained by setting the amplitude near full-scale and using external
attenuators on the output.
3) Indicate the desired polarity by suffixing model number with -P or -N (i.e. positive or negative) or -PN for the dual polarity option.
4) The -OS option adds an internal bias tee circuit to the output, allowing an externally-generated DC offset (±50V/250mA max) to be
added the output signal. The -OT option includes the -OS function, and adds the ability to generate a ±5V/100mA offset internally
(controlled from the front panel, or by computer command on -B units).
5) Add -M to model number for monitor option.
6) A 50 Ohm load is required. Other loads may damage the instrument. Consult Avtech (info@avtechpulse.com) if you need to drive other load
impedances.
7) The pulse width thresholds are approximate.

SPECIFICATIONS

AVPP-2-B
0.5 ns - 100 ns
1 Hz - 100 kHz
1%
Check http://www.avtechpulse.com/labview
Included. Recommended as a modern alternative to GPIB / RS-232.
See http://www.avtechpulse.com/options/vxi
Not calibrated. For high-accuracy applications requiring traceable calibration,
verify the output parameters with a calibrated oscilloscope.
Optional 4 . Apply required DC offset to back panel solder terminals(250 mA / ±50V maximum).
Internal trigger, external trigger (TTL level pulse, > 10 ns, 1 kΩ input impedance),
front-panel "Single Pulse" pushbutton, or single pulse trigger via computer command
0 to 1.0 seconds, for all trigger modes (including external trigger)
+3 Volts, > 50 ns, will drive 50 Ohm loads
Provides a 20 dB attenuated coincident replica of main output
Out, Monitor: SMA female.
Add the suffix "-AK1" to the model number to include the recommended accessory kit.
Consists of three SMA, 18 GHz, 2 Watt attenuators (10, 20 & 30 dB)
for use on the output, and two 50 Ohm, 1 GHz, 1 Watt feed-through terminators
(one SMA, one BNC) for use on external trigger inputs.
Add the suffix "-AK8" to the model number to include the recommended accessory kit.
Consists of one 12-inch SMA-M/SMA-M PE-SR405FL coaxial cable, one 12-inch
SMA-M/SMA-M RG-316 coaxial cable, one 36-inch SMA-M/SMA-M RG-316 coaxial cable,
one 24-inch SMA-M/BNC-M RG-316 coaxial cable, one 36-inch BNC-M/BNC-M RG58C/U
coaxial cable, one SMA-F to BNC-M adapter, one SMA-M to BNC-F adapter, one SMA-F to
SMA-F adapter, and one SMA-F to solder cup adapter
100 mm x 430 mm x 375 mm (3.9" x 17" x 14.8")
cast aluminum frame & handles, blue vinyl on aluminum cover plates
< 2 - 20 Volts
≤ 200 ps
< 200ps, for > 8 ns PW
< 500ps, for < 8 ns PW
Standard on -B units
50 Ohms 6
Positive or negative or both (specify)
for availability and downloads
≤ 150 ns (Ext trig in to pulse out)
± 35ps ± 0.015% of sync delay
Trig, Sync, Gate: BNC female.
100 - 240 Volts, 50 - 60 Hz
+5°C to +40°C
AVPP-2A-B
0.5 ns - 1 us
1 Hz - 100 kHz
5%
for details.
6
