Rev 1.0
1.4 Standard Faceplate Connections
The functions of the standard connectors on the SMx
follows:
GNSS
USB-C
Ethernet
1.4.1 Power Connector: 4-pin PT07
Pin
A
Main Power Input; 9.5– 24VDC
B
Battery Power Input; 11 – 20VDC
Primary power is supplied to the SMx
separate ground connection can be attached to the quick-disconnect spade attached to
the power connector.
CAUTION
NOTE: The internal battery, when installed, is only charged when Power A is
above 14VDC. It is not charged from Pin B. An external battery on Pin B
can also be charged when Power A is above 14VDC.
Reftek Systems Inc.
180-SMx2 Users Guide
180-SMx2-UG
Description
2
DAS unit through the power connector. A
Disk operations are suspended when the input voltage drops below a user-
settable threshold (above 10V).
2
Seismic Recorder faceplate are as
Vent: DO NOT REMOVE
Pin
Description
C
Ground
D
Ground
11/29/2022
Power
3
