Meaning Icon
TIME
ACQ
Vin
WIFI
SLINK
RTPD1
RTPD2
RAM%
USB%
USB
Reftek Systems Inc.
180-SMx2 Users Guide
180-SMx2-UG
Off Green
n/a Reference
Clock last
locked within
the last hour
n/a Acquisition is
on and no
non-
continuous
triggers are
active
n/a Input voltage
is at or above
13.0 V
Wi-Fi is off Wi-Fi is on
and the
mobile
device is
connected
via Wi-Fi
No clients One client is
are connected
connected
Not Connected
configured
Not Connected
configured
n/a Less than
20% total
RAM used
n/a Less than
33% total
USB used
n/a USB off and
no data read
or write
errors
White Orange
Reference Reference
Clock last Clock last
locked locked
between 1 – longer than
4 hours ago 4 hours ago
Acquisition is n/a
on and at
least one
non-
continuous
trigger is
active
Input voltage Input
is less than voltage is
13.0 V and at below 11.5 V
or above and not in
11.5 V LVD
Wi-Fi is on Wi-Fi is
but the turning on
mobile
device is not
connected
via Wi-Fi
Multiple n/a
clients are
connected
n/a n/a
n/a n/a
Between 20% Between
and 80% 20% and
total RAM 80% total
used, and at RAM used,
least one RTP and at least
link using one RTP link
less than using more
20% of total than 20% of
RAM total RAM
Between 33% Between
and 66% 66% and
total USB 99% total
used USB used or
more than
99% total
USB used
and Disk
Wrap is
enabled
n/a USB on
11/29/2022
Red
Reference
Clock has not
locked since
boot
Acquisition is
off
Input voltage
is below 11.5
V and in LVD
n/a
n/a
Not
connected
Not
connected
More than
80% total
RAM used
More than
99% total
USB used
and Disk
Wrap is
disabled
USB off and a
read or write
error
occurred
