Rev 1.0
was off are corrected before the 184-GNSS is turned off again. The 184-GNSS can be
operated in three modes.
Mode
Duty-cycle Powers down the 184-GNSS and awakens the 184-GNSS and repeats the above phase locking
algorithm each hour at 40 minutes after the hour.
Continuous Leaves the 184-GNSS powered on continuously.
Off Powers down the 184-GNSS and does not turn the 184-GNSS power back on.
2
The SMx DAS can also use a PTP Grandmaster or an NTP server through the internet instead of
the external 184-GNSS. These time sources are not as precise, but do not require a dedicated
184-GNSS for each DAS.

2.6 Ethernet for Configuration

As shipped from the factory, the recorder uses a link-local connection, which allows its
Ethernet cable to be plugged into any existing Ethernet network. The SMx
default to a fixed link-local IP address of 169.254.109.109.
NOTE: Only one factory default recorder can be connected to a network
until the default IP address has been changed to a new, unique IP address.
From a computer on the same network as the recorder, open a web browser and
2
connect to the SMx link-local IP address as follows: http://169.254.109.109. Check the
status of the DAS using the Status tab and sub-menus.

2.7 Using a Mobile Device for Configuration

2
The SMx DAS includes an internal Wi-Fi hotspot that allows a mobile device to connect
directly to the Web UI for configuration.
1. On the mobile device, enable Wi-Fi from its system Wi-Fi settings.
2. Wave the magnet on the DAS to turn on the Wi-Fi hotspot.
3. On the mobile device, select the SMx
seconds for it to show up on the Wi-Fi list.
4. If a warning pops up indicating Internet connections are not possible, choose an option to
stay connected/continue. This is device/OS dependent.
5. On the mobile device, exit the Wi-Fi settings and open a web browser.
6. Enter the IP address of the DAS to display the configuration Web UI.
7. Check the status of the DAS using the Status tab and sub-menus.
Reftek Systems Inc.
180-SMx2 Users Guide
180-SMx2-UG
Description
2 DAS you want to connect to. This may take a few
11/29/2022
2 recorder will
13
