Installation option - converting
from desktop to wall mount position
To mount the telephone base on the wall
1. Put the corded handset aside. On the
telephone base, place a coin in the slit of
the wall mount clip and rotate a half turn
(180°).
• It locks into place with the protruding
edge pointing towards the upper edge of
the telephone base. This protruding edge
holds the corded handset when the phone
is mounted on the wall.
2. Turn the telephone base over with the
bottom side facing up. Press the tabs of the
mounting bracket as the direction indicated
to release and remove the mounting
bracket from the telephone base.
3. Rotate the mounting bracket. Insert the
tabs of the mounting bracket into the
middle grooves on the telephone base
as shown below. Then press the tabs and
push the mounting bracket into the lower
grooves on the telephone base until they
lock securely.
4. Mount the telephone base on the wall by
positioning the eyelets on the telephone
base and the mounting bracket against the
mounting studs. Then slide the telephone
base down on both mounting studs until it
locks into place.
5. Replace the handset on the telephone
base cradle.
EN - 8
Protruding
edge
Mounting
bracket
Eyelets
