Installation, Precautions & Servicing

This product is only suitable for well insulated spaces or occasional use

Carefully remove the fire from the packing checking neither the heater nor the power

cable has been damaged during transport. Do not operate the fire if damaged.

The accessories are found in a box that is packed at the side of the fire.

Always read this manual first before attempting to install or use and keep in a safe place.

Your fire is guaranteed for three years from the date of purchase.

ALL INSTRUCTIONS MUST BE HANDED TO END USER FOR SAFE KEEPING

MODELS

E-FX & E-FX Lite

1000

1300

1500

1800

Important

Please bear in mind the weight of the fire before

removal from the packaging and installation.

Consider if help is required.

240V

Need help?

Do you have a question about the E-FX and is the answer not in the manual?

Questions and answers

Summary of Contents for Flamerite Fires E-FX

Page 1 Installation, Precautions & Servicing This product is only suitable for well insulated spaces or occasional use MODELS E-FX & E-FX Lite 1000 1300 1500 1800 Important Please bear in mind the weight of the fire before removal from the packaging and installation.
Page 2 Contents Important Safety Information and Warnings UCKA Declaration CE Declaration Technical Specification Installation Instructions Non Reflective Rear Screen Option Fuel Effects Glass Fitting & Removal Information Requirements Maintenance & Trouble Shooting Wiring Diagrams Recycling Registration No WEE/DH1656ZW In accordance with European Directive 2012/19/ EU, waste electrical and electronic equipment (WEEE) must not be disposed of with household waste.
Page 3 BS-EN 60335-1:2012 + A11:2014 + A13:2017 + A1:2019 + A14:2019 + A2:2019 BS-EN 55014-1:2017 BS-EN IEC 6300 :2018 BS-EN 55014-2:2015 BS-EN 301 489-1 BS-EN61000-3-2:2014 BS-EN 300 489-3 BS-EN 61000-3-3:2013 BS-EN 300 220 BS-EN 50564:2011 BS-EN 60675:1995+A11:2019 Manufactured by: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs. WS13 7AU. UK...
Page 4 EN 61000-3-3:2013 EN 300 220 EN 50564:2011 EN 60675:1995+A11:2019 Manufactured by: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs. WS13 7AU. UK Technical Specification A 230V 13A 50Hz supply is required. Maximum power consumption: 1500 Watts A 1.8 metre lead with a BS1363 plug containing a BS1362 13A fuse is supplied with this appliance.
Page 5 WARNING DO NOT TWIST, FORCE OR SQUEEZE THE FIRE DURING THE INSTALLATION PROCESS. THERE MUST BE ENOUGH CLEARANCE FOR THE FIRE TO COMFORTABLY FIT INSIDE OR AGAINST A WALL. DO NOT SQUEEZE INTO AN OPENING AS THIS MAY DEFORM THE CASE AND STOP THE GLASS FROM MOVING CORRECTLY.
Page 6 Installation Instructions E-FX Side panels for 1 or 2 sided corner fitting. If fitting as a 1 or 2 sided corner fire, blanking panels will need to be fitted. Each blanking panel consists of two parts fitted directly over the side glass. If you need to fit the blanking panel(s) follow the instructions and images below.
Page 7 If purchased as a fire only or as a standard wall mount suite, the height at which you may wish to fix the fire in or on the wall is up to you. When purchased as part of a E-FX Media Wall, refer to those instructions. If purchased with a Plinth or Contemporary legs, the height you will need to fit the...
Page 8 Lower Bracket Fixings 1000 1300 1500 1800 60mm screws M10 rawl plugs M6 screws M6 washers Remove the screws and washers (remove the lower bracket only). Mark up and drill the holes with an M10 bit and fit the rawl plugs. Using the screws, secure the bracket to the wall.
Page 9 Top Bracket Fixings 1000 1300 1500 1800 60mm screws M10 rawl plugs 13mm screws A second person will be required. For now, leave the top bracket attached. Place and hold the fire on the lower bracket. Keeping the fire firmly pushed against the wall, mark across the length of the top bracket and into the slots above each hole.
Page 10 Before any further work is completed now your fire is secure, make sure the mains cable is tightly fitted underneath the fire. You can use the two holes circled in red below to keep the power cable in place using a cable tie.
Page 11 Not available with E-FX Lite As standard one of the two rear screens in the E-FX fire has a reflective coating to mirror the log effect. When the fire is on, the flame simulates a 3 dimensional burn between the actual log effect and the reflection generated by the coating.
Page 12 You will need to carefully remove both screens, to do this unscrew the top bracket holding them in place. Using the foam tape provided in the accessory pack, apply across the length of the top bracket’s front face to keep the projection screen secure. Now the reflective glass screen has been removed, screw the bracket back into place and refit the projection screen.
Page 13 Fuel Effects WARNING: DC SUPPLY 12V IMPORTANT: FUEL EFFECTS MUST BE POSITIONED ACCORDING TO THE E-FX LOG INSTRUCTION BOOKLET. CARE MUST BE TAKEN TO ENSURE THE CHANNEL AT THE FRONT OF THE FIRE IS NOT OBSTRUCTED. ANYTHING DROPPED IN DURING FITTING OF THE FUEL EFFECTS, MUST BE REMOVED BEFORE INSTALLING THE FRONT GLASS PANEL.
Page 14 Place the handle (D) onto the top right-hand side of the glass. The upper glass rail is magnetic and will easily fix into place along the top of the opening (E). Adjust the position of the handle (D) to fit into the gap on the rail.
Page 15 Type of heat output/ room temperature control With distance control option Room temperature control, with open window detection Adaptive Start With electronic room temperature control plus week timer Contact Details: Flamerite Fires Ltd. WS13 7AU. UK. www.flameritefires.com E-FX LITE Model identifier (s) 1000 1300 1500...
Page 16 Maintenance & Trouble Shooting WARNING BEFORE ANY MAINTENANCE IS UNDERTAKEN, ALWAYS DISCONNECT THE FIRE FROM THE MAINS POWER SUPPLY. Maintenance must be undertaken by a Flamerite service engineer or similarly qualified persons in order to avoid a hazard. Replacements part are available from www.flameritefires.com PROBLEM POSSIBLE CAUSE SOLUTION...
Page 17 Remote Control non responsive Lost RF connection to fire Turn fire off & on using the rocker (Flashing red when pressing switch next to keypad and repair buttons instead of green) the remote. See App instructions. Batteries Replace with 2 x AAA Front glass will not glide freely Debris from fuel bed in channel Remove...
Page 18 Wiring Diagram...
Page 19 Parts List – Fire PART PART NAME PART CODE NUMBER E-FX E-FX E-FX E-FX 1000 1300 1500 1800 1000 1300 1500 1800 Lite Lite Lite Lite Top Hanging Bracket Bottom Hanging Bracket Power Lead E90-1 E90-1 E90-1 E90-1 E90-1 E90-1...
Page 20 Parts List – Fire...
Page 21 NOTES...
Page 22 Manufactured by Flamerite Fires Ltd Greenhough Road, Lichfield. Staffordshire. WS13 7AU. UK +441543 251122...
