  • Page 1 SUITE INSTALLATION, PRECAUTIONS & SERVICING E-FX & E-FX Lite...
  • Page 2 IMPORTANT • • Please make sure that the fire We recommend fully installing is fitted at the correct height for and setting up the fire prior the suite purchased. There are to suite installation to prevent different heights required for the unnecessary damage to the plinth, contemporary legs, and suite or surrounding woodwork.
  • Page 3: Table Of Contents

    CONTENTS Recycling & Safety Warnings ............................. 4 Technical Specifications ............................. 6 Fitting The Suite ................................8 Installing The Trims ..............................12 FAQs ....................................14 Notes ....................................37 E L E C T R I C F I R E S M A D E I N E U R O P E...
  • Page 4: Recycling & Safety Warnings

    RECYCLING & SAFETY WARNINGS IMPORTANT REGISTRATION NO WEE/DH1656ZW • In accordance with European Directive 2012/19/ EU, waste electrical and electronic equipment (WEEE) must not be disposed of with household waste. • Please recycle responsibly. DETAILS • • WARNING: In order to avoid overheating, This appliance can be used by children do not cover the heater.
  • Page 5 RECYCLING & SAFETY WARNINGS • Children of less than 3 years should be due to overheating. The element will kept away unless continuously supervised. continually and automatically cut out if the airflow is obstructed. Never cover the • Children aged from 3 years and less air outlets.
  • Page 6: Technical Specifications

    TECHNICAL SPECIFICATIONS FRONT VIEW WALL HANGING WITH LEGS WITH PLINTH E L E C T R I C F I R E S M A D E I N E U R O P E...
  • Page 7 TECHNICAL SPECIFICATIONS SUITE MODEL PAYTON 1000 PAYTON 1300 ELARA 1000 ELARA 1300 1400mm / 55 1/8 1700mm / 66 15/16 1400mm / 55 1/8 1700mm / 66 15/16 140mm / 5 1/2 140mm / 5 1/2 140mm / 5 1/2 140mm / 5 1/2 140mm / 5 1/2 140mm / 5 1/2...
  • Page 8: Fitting The Suite

    FITTING THE SUITE Using a screwdriver, bend out the tabs located around the top and bottom lips to 90 degrees. They are used to help locate the suite in position. E L E C T R I C F I R E S M A D E I N E U R O P E...
  • Page 9 FITTING THE SUITE Next you fit the top section of the suite. Slide the top on with the cut-out sliding in-between the tabs you just bent out. You will need to push to all the way back to the wall. Make sure that the down lighting cable is tucked into the slot provided.
  • Page 10 FITTING THE SUITE Place the bottom of the suite in front of the fire, and plug in the down lights into the sockets. Make sure that you turn the switches on before fitting the suite fully. If you have a LED kit with your fire, you will need to plug this in now.
  • Page 11 FITTING THE SUITE Slide the bottom onto the fire, making sure that the cut-out slides between the tabs you folded out earlier in step 1 again. When it is in position, make sure the down light cable is tucked into the slot shown below and secure the woodwork with the black 12mm screws found in the accessory pack.
  • Page 12: Installing The Trims

    INSTALLING THE TRIMS Next you can unwrap and install the fire side cheeks. These are magnetic and come with a cut-out for the down lighting cable. You can place them onto the side of the fire making sure you tuck the down lighting cable into the cut-out.
  • Page 13 INSTALLING THE TRIMS Unwrap the wall panels and wipe the wall using the alcohol wipes provided in the accessory pack, making sure it is free of grease and dust. Peel off the tape cover on the back of the panels and press them firmly against the wall.
  • Page 14 INSTALLING THE TRIMS Unwrap the metal suite trims and make sure you have two side trims, and one front trim. The side trims should have 2 magnets spaced on the under side of each, and the front trim should have 4 or 6 magnets depending on the size of your fire. The trims are magnetic so you can just place them into position, and make any small adjustments to close up the gaps by pushing the trims into place.
  • Page 15: Faqs

    FAQS Q How do I pair and work my down lights? A Please refer to the Cloud eControl App Instruction manual. Alternatively there is a switch located under the top right of the suite. Q Why are my down lights not working? A Make sure the switch inside the suite is turned on and the plugs are seated properly.
  • Page 16 TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Check lead in plugged in securely and p-clipped in place Mains lead not plugged in (PAGE 17-23) NO POWER TO FIRE Circuit board Replacement part required (QUOTE PART NUMBER E50) Mains socket Check socket is switched on Dimmer turned down Use remote or app to adjust the dimmer settings NO LIGHTING OR...
  • Page 17 TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Turn fire off & on using the rocker switch next to keypad Lost rf connection to fire and repair the remote. See App instructions. REMOTE CONTROL NON RESPONSIVE Batteries Replace with 2 x AAA Debris from fuel bed Remove debris in channel FRONT GLASS WILL...
  • Page 18: Notes

    NOTES E L E C T R I C F I R E S M A D E I N E U R O P E...
  • Page 19 NOTES E L E C T R I C F I R E S M A D E I N E U R O P E...
  • Page 20 These products are only suitable for well insulated spaces or occasional use. Manufactured in the United Kingdom. All products are protected by patents, registered design and intellectual property rights. Flamerite Fires Ltd. will protect these rights. All specifications are correct at the time of publishing but are subject to change.
