CONTROLS: KNOBS
EFFECT (not labeled)
The effect knob selects which filter type will be used. There are
positions ( through
0
In the mode, the envelope filter effect is bypassed but the
EQ ONLY
equalizer still applies. For information on the individual settings see the
Effect Types section.
2 POLE LOW PASS
SWEEP RANGE
In Envelope and Hot Hand modes, the sweep range knob controls the
direction and breadth of the filter sweep. The right side of the knob
(labeled ) adjusts the breadth of the upward sweep, adding greater
UP
range as you turn the knob clockwise. The left side of the knob (labeled
) adjusts the breadth of the downward sweep, adding greater
DOWN
range as you turn the knob counterclockwise. In
controls the depth of the upward and downward sweep, but keep in mind
that symmetric
LFO
random) will sound the same in either sweep direction. Conversely,
non-symmetrical
sound very different, depending on the direction of the sweep.
