Source Audio SA144 User Manual page 26

MIDI Channel (Effect Knob)
The label numbers around the effect knob correspond to Channels
MIDI
through . Channel 1 is the default. This is a global setting and not
1 16
saved for individual presets.
Don't forget to save the preset after editing the Backpage parameters.
All of the Backpage parameters except the Channel are saved per
MIDI
preset. To reset values to the default, press both left and right column
select buttons at the same time.
(XD) (XC) (OE) (VA) (Q) (EL) (LS)
+12
USER
0
-12
125 250 500 1K 2K 4K 8K
PRESS PRESS
< >
Press both left and right column select buttons at
the same time to reset values to the default.
Restoring Factory Settings
The following procedure can be used to restore the factory settings to the
Poly-Mod Pro:
Press and hold the Preset Bank butting while plugging in the power
DC
supply. Note that this will also delete all saved presets and User
MIDI
sequences.
1-3 4-6
PRESS
PRESET BANK
26 | Backpage Parameters
