1 Antenna
2 3 - Level Sound Indicator
• Green: low sound level is detected by the baby unit.
• Green and amber: moderate sound level is detected by the baby unit.
• Green, amber and red: high sound level is detected by the baby unit.
3
Battery LED Indicator
• On when the parent unit is connected to AC power, and the battery is charging.
• Flashes when the parent unit battery is low and needs to be charged.
4 LINK LED Indicator
• On when the parent unit is linked to the baby unit.
• Flashes when the link to the baby unit is lost.
| | |
5
• Press to navigate leftward, upward, rightward or downward, within the main menu
and sub-menus.
• While viewing a zoomed image, press to move the image leftward, upward, rightward
or downward.
6
Menu/Select/Zoom
• Press to enter the main menu.
• While in a menu, press to choose an item, or save a setting.
• Press to zoom in/out.
7
/ TALK
• Press and hold to talk to the baby unit.
• While in a sub-menu, press to exit.
8
/ POWER LCD on/off / Power on/off
|
9
10 Microphone
11 Power Jack
12 RESET
Force reboot the parent unit.
13 Speaker
Arrow Keys
Increase or decrease parent unit volume.
