BM5350N

BM5350N-2

Motorised Pan/Manual Tilt

Video Monitor

User Guide

This guide contains important information.

Please keep it for future reference.

Table of Contents

Need help?

Do you have a question about the BM5350N and is the answer not in the manual?

Questions and answers

Summary of Contents for VTech BM5350N

Page 1 BM5350N BM5350N-2 Motorised Pan/Manual Tilt Video Monitor User Guide This guide contains important information. Please keep it for future reference.
Page 2: Table Of Contents
Temperature ...........................26 Turn on/off Alert Tones ......................27 Adjust Baby Unit Speaker Volume ..................28 Dim Mode ..........................29 Night Vision ...........................29 Monitoring Modes (BM5350N-2 only) ...................30 Additional Information ��32 Wall Mount (Optional) ......................32 General Product Care ......................35 Storage ..........................35 Technical Specifications ......................35 Customer Service and Product Warranty ................36...
Page 3: Important Safety Instructions
20. You should test the sound reception every time you Parent unit output: 5V DC 1A turn on the units or move one of the components. VTech Telecommunications Ltd. 21. Periodically examine all components for damage. Model: VT05EAU05100 Baby unit output: 5V DC 1000mA 22.
Page 4 Electromagnetic fields (EMF) reach of children (more than 3 ft (0.9m) away). Do not remove warning label on This VTech product complies with all standards regarding the adaptor cord. electromagnetic fields (EMF). If handled properly and according to the instructions in this user’s manual, the •...
Page 5: Setup
Parent Unit Baby Unit Wall Mount Bracket Parent Unit Adaptor Baby Unit Adaptor Quick Start Guide 1 set for BM5350N Learn to set up your units and have all detailed instructions on using your baby 2 sets for BM5350N-2 monitor.
Page 6: Overview
Overview Baby Unit...
Page 7 Light Sensor Camera Gloss lens Microphone Night light ON/OFF switch • Slide to turn on or off the baby unit. POWER LED light • On when the baby unit is turned on and is paired to the parent unit. • Flashes when the baby unit is not being viewed; or when the link to the parent unit is lost. Speaker Night light on/off key •...
Page 8 Parent Unit...
Page 9 LED lights LCD display Microphone POWER TALK MENU/SELECT Arrow keys • While viewing image from the baby unit, press and hold to pan the baby unit leftward or rightward. • Press to navigate leftward, upward, rightward or downward, within the main menu and sub-menus.
Page 10: Parent Unit Icons
• Play all melodies. • Set timer to stop playing the selected melody or soothing sound. Camera Settings Baby unit speaker volume • Adjust the baby unit’s speaker volume. Monitoring mode (For BM5350N-2 only) • Single mode • Split mode • Patrol mode...
Page 11 Night light Turn on/off night light. • Select one of the night light colours. • Change to all seven colours in cycles. • Set timer to turn the night light off. • Select to set the night light to always on. •...
Page 12 • Set the confirmation tone on or off when selecting an option in the menus. • Set the parent unit to beep when the baby unit detects sounds while in Split mode (For BM5350N-2 only). Temperature • Turn on/off temperature alert tone.
Page 13 - Moderate signal strength • - Low signal strength • - Weak signal strength Split mode For BM5350N-2 only) Patrol mode For BM5350N-2 only) Current view status • The baby unit number that is being viewed when in: - Single CAM mode.
Page 14 • Displays when connection between parent unit and baby unit is lost. • Displays when sound is detected at a baby unit when in Split view. (For BM5350N-2 only) • Baby unit detects temperature reaches or exceeds the set maximum.
Page 15: Connect The Baby Monitor
Connect the Baby Monitor Connect the parent unit and baby unit to a power supply with the included power adaptors. Notes: • The rechargeable battery in the parent unit is built-in. • Use only the power adaptors supplied with this product. •...
Page 16: Charge The Parent Unit Battery
Charge the Parent Unit Battery The parent unit operates on an internal rechargeable battery or AC power. To continuously monitor your baby, keep the parent unit connected to AC power. When the parent unit is used on the internal batteries, the operating time will vary according to the initial state of charge and the settings.
Page 17: Position The Baby Monitor
Positioning the Baby Monitor Caution: Keep the baby unit out of the reach of your baby. Never place or mount the baby unit inside the baby’s crib or playpen. 1� Place the baby unit more than 3 feet (1m) away from your baby. 2�...
Page 18: Basic Operation
Basic Operation Power on/off 1� Slide the power switch to ON to turn on your baby unit. Slide to the opposite direction to turn off. 2� Press and hold POWER to turn on the parent unit, the welcoming screen appears and the LINK LED flashes. Raise the parent unit antenna for better reception.
Page 19: Status Check
Status Check Once your baby unit and parent unit are powered on, the parent unit and baby unit will link to each other automatically. When they are connected successfully, the LINK LED lights steadily. And your parent unit streams live video from the baby unit. The ON LED light of baby unit turns on.
Page 20: Adjust Speaker Volume
Adjust Speaker Volume Press to adjust the parent unit speaker volume level received from the baby unit. Talk to Your Baby via the Baby Unit You can use the TALK function on the parent unit to comfort your baby from the other room.
Page 21: Zoom
Zoom Press to zoom in and out. You can zoom between 1x and 2x� Turn on/off the Parent Unit Screen You can turn on or turn off the parent unit screen without powering off the unit. You will still hear sounds from the baby unit. LCD ON/OFF •...
Page 22: Advanced Operation
Advanced Operation Adjust Screen Brightness You can change the brightness of the parent unit screen from Level 1 to Level 5. The LCD screen brightness is preset to Level 3. To adjust LCD brightness: 1� Press on the parent unit to select (Brightness).
Page 23: Night Light
Night Light You can control the night light remotely on the parent unit or directly on the baby unit. On the Baby Unit Press the Night light on/off key located on the back of the baby unit to turn on/off the night light. On the Parent Unit 1�...
Page 24: Sound Sensitivity And Sound Activation
If you have turned on Sound Alert, the parent unit beeps when the baby unit detect sounds while in Split mode (For BM5350N-2 only). Adjust VOX Sensitivity Level You can set VOX (Voice Activated Alert) sensitivity level to activate parent unit screen and sound when baby unit detects sounds that exceed certain levels.
Page 25 Turn on or off Sound Activation When Sound activation is on, the parent unit screen stays off to save power when the baby unit detects no sound. Once the baby unit detects sounds that are louder than the chosen sound sensitivity level, the parent unit screen and speaker turn on automatically.
Page 26: Temperature
Temperature Temperature Alert Your baby unit can help you keep track of your baby’s room temperature in order to ensure that your baby stays in the comfort zone at all times. With temperature sensor, the relevant data will be shown on the status bar when you powered on your units.
Page 27: Turn On/Off Alert Tones
Turn on/off Alert Tones Low Battery Alert Tone You can set the parent unit to beep when the parent unit operates in low battery condition. Switch it off if you do not wish to be disturbed when the parent unit’s battery is running low.
Page 28: Adjust Baby Unit Speaker Volume
Sound Detection in Split Mode Alert Tone You can turn on sound alert, and set the parent unit to beep when the baby unit detects sounds while in Split mode (For pairing with BM5350N-2 only). Turn on or off sound alert: 1�...
Page 29: Dim Mode
Dim Mode Dim mode helps you save parent unit power. When your parent unit is not charging, the display will automatically dim after 10 minutes of inactivity if no keys are pressed or alerts are received from the baby unit. 10 min inactivity Press any button Night Vision...
Page 30: Monitoring Modes (Bm5350N-2 Only)
Monitoring Modes (BM5350N-2 only) When more than one baby unit is paired to the parent unit, you can choose to view different baby units in three monitoring modes. Learn more about each below: Single Mode The screen displays images only from the selected baby unit in full screen.
Page 31 Change different views - Single CAM In Single CAM or Patrol mode, press VIEW to switch between the image of baby units Press VIEW Press Change different views - Patrol Select Patrol as your monitoring mode to alternately view the image from baby units every 10 seconds.
Page 32: Additional Information
Additional Information Wall Mount (Optional) Notes: • Check for reception strength and camera angle of the baby unit before drilling the holes. • The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your baby units.
Page 33 3� Align the wall mount bracket and screws with the holes in the wall as shown. Tighten the screw in the middle hole first, so that the wall mount bracket position is fixed. You can tighten the other screw in the top hole. Insert the screws into the holes and tighten the screws until only 6.5 mm of the screws are exposed.
Page 34 Place the baby unit on the wall mount bracket, and then slide it forward until it locks into place. Align the holes on the wall mount bracket with the screws on the wall, and slide the wall mount bracket down until it locks into place. 5�...
Page 35: General Product Care
General Product Care To keep this product working well and looking good, follow these guidelines: • When you are not going to use the video monitor for some time, store the parent unit, the baby unit and the adaptors in a cool and dry place. •...
Page 36: Customer Service And Product Warranty
24 months from date of purchase. VTech does not warrant that the product will be free from defects if defects are caused by an accident, misuse, abuse, improper installation or operation, vermin infestations, lack of reasonable care, unauthorised modification, loss of parts, tampering or attempted repair by a person not authorised by VTech;...
Page 37: Disposal Of Batteries And Product
Disposal of Batteries and Product The crossed-out wheelie bin symbols on products and batteries, or on their respective packaging, indicates they must not be disposed of in domestic waste as they contain substances that can be damaging to the environment and human health. The chemical symbols Hg, Cd or Pb, where marked, indicate that the battery contains more than the specified value of mercury (Hg), cadmium (Cd) or lead (Pn) set out in Battery Directive (2006/66/EC).
