ASSEMBLY INSTRUCTIONS
Quadro Square
Counter table
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
STEP 06
Place desktop ontop of frame. Nut inserts in top will align with plastic
joiner brackets using M6x30MM (I) sockets attach top to frame.
All manuals and user guides at all-guides.com
www.jasonl.com.au
Need help!
Call us on
1300 527 665
I
nut insert
TABLE TOP
BOTTOM VIEW
nut insert
Page 6 of 6
