ASSEMBLY INSTRUCTIONS
Quadro Square
Counter table
Sizes: 1200x700, 1400x700, 1600x700, 1800x700 mm
STEP 01
E
Using Allen Key provided, attach 2 plastic brackets per leg (D)
(as per picture above) using M6x20MM (H) Socket head screw.
Screw the feets (E) to the bottom of each leg (B)
All manuals and user guides at all-guides.com
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 02
H
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B)
TOP VIEW
G
