- Page 1 SATATYA PZCR50ML42CWP Installation Guide...
- Page 2 Please read this guide first for correct installation and retain it for future reference. The information in this guide is prevailing at the time of publication. However, Matrix Comsec reserves the right to make changes in product design and specifications without prior notice.
-
Page 3: Table Of Contents
Table of Content Package Contents ............................4 Cautions ..............................4 System Requirements ..........................4 Hardware Overview ........................... 5 4.1 PTZ Camera with 5MP 42X Optical Zoom .................... 5 4.2 B41 Wall Mount Bracket ........................6 Camera Dimensions ........................... 7 Things you will need ..........................8 Hardware Installation .......................... -
Page 4: Package Contents
SATATYA Network Camera. For more details, please refer to the System Manual. 1. Package Contents Before installation, please verify that all the necessary items are supplied in the box as the package contents listed below. If any item is missing or damaged, please contact Matrix sales representative. Items Quantity... -
Page 5: Hardware Overview
4. Hardware Overview 4.1 PTZ Camera with 5MP 42X Optical Zoom Note: 1) PoE and AC 24V is available for PTZ Camera power supply. 2) Built-in SD card slot can be seen after removing the 4 screws and open the front panel;... -
Page 6: B41 Wall Mount Bracket
4.2 A41 Wall Mount Bracket Accessories Map* Note: External Corner Bracket, Pole Mount and Junction Box are accessories that can be used according to your installation scenario but are not provided by Matrix. -
Page 7: Camera Dimensions
5. Camera Dimensions... -
Page 8: Things You Will Need
Wall Mount Ceiling Mount (the accessories are not provided by Matrix for this installation scenario) 7.1 PTZ Camera with 5MP 42X Optical Zoom Step1: Check the wall or ceiling condition. Ensure that there is sufficient strength to avoid flaking. - Page 9 Step3: Put the cables through the holder. Match the holder with the screw holes of the camera body and secure them; Step4: Make sure that the camera body has been correctly installed to the holder, and match the holder to the holes on the wall or ceiling, then tighten up the screws.
-
Page 10: Adjusting The Camera Angle
Adjusting the Camera Angle Camera angle can be adjusted via PAN Movement and Tilt Movement, refer to the table below for PAN and Tilt Movement Range. Parameter Name PZCR50ML42CWP PAN Range 360 degree endless Manual: 0.1°~400°/s PAN Speed Preset: 400°/s Tilt Range 0°~90°(Auto Flip) Manual: 0.1°~320°/s... -
Page 11: How To Connect To Alarm Interface
7.4 H ow to Connect to Alarm Interface External interface of camera is as the following, you can refer to the picture to install the external alarm device: PIN1: Alarm Output NC/NO 24V DC 1A PIN2: Alarm Output NC/NO 24V DC 1A PIN3: Alarm Input NC/NO ≤12V PIN4: Alarm Input NC/NO ≤12V... -
Page 12: How To Connect The Water-Proof Connector
7.5 How to Connect the Water-proof Connector Step1: Get the network cable through the screw nut, rubber ring and the screw bolt; Step2: Insert the rubber ring into the screw bolt; Step3: Connect the screw nut to the screw bolt; Step4: Place the O-Ring on the network port connector;... -
Page 13: Recommended Method Of Outdoor Installation
8. Recommended method of outdoor installation The picture below shows an example of outdoor installation The devices represented by numbers in the picture are explained as follows: ① Lightning rod ② Video surge arrester ③ Telecommunication surge arrester ④ Power surge arrester ⑤... -
Page 14: Hardware Reset
9. Hardware Reset Step1: Press the reset button and hold on, then power on the network camera and the IR LEDs will begin to twinkle; Step2: Loosen the reset button, then the camera begins to reset; Step4: It will take 1~3 minutes to complete the reset and the IP will turn into 192.168.1.126 (If the IP does not change, please try again from step 1.);... -
Page 15: Accessing The Satatya Network Camera
10. Accessing the SATATYA Network Camera The camera must be assigned an IP address to be accessible. 10.1 Assigning an IP Address The Network Camera must be assigned an IP address to be accessible. The default IP address of SATATYA Network Camera is 192.168.1.126. You can either change the IP address of the camera via browser. - Page 16 Step2: Open the browser. In the address bar, enter the default IP address of the camera: http://192.168.1.126; Step3: Enter the user name and password when the LOGIN page appears; (Default user name: admin; Default password: admin) Note: (1) Password must be 8 to 32 characters long, contain at least one number and one letter. (2) You can click the “forget password”...
-
Page 17: Accessing From The Web Browser
Step4: After login, please click “Configuration” “Basic Settings” “Network” “TCP/IP”. The Network Settings page appears . Step5: Change the IP address or other network values. Then click “Save” button; Step6: The process of changing the default IP address is completed. 10.2 Accessing from the Web Browser The camera can be used with the most standard operating systems and browsers. - Page 18 Step4: Follow the prompts to install the Controls, when it`s finished, it will pop out a window as below. Please click “Finish” and refresh the browser, then you will see the video. If IE9 or higher version browser is used, it is suggested that the SATATYA camera web link should be added as a trusted site.
- Page 19 Figure 8-15 Step3: Enter the IP address of the camera in the blank and click “Add”; Figure 8-16 Step4: Enter the IP address. After logging on Network Camera’s web GUI successfully, user is allowed to view live video as follows.
-
Page 20: Technical Specification
11. Technical Specification SATATYA PZCR50ML42CWP Image Sensor 1/2.8" CMOS Min. Illumination Color: 0.005Lux@F1.2 Color: 0.008Lux@F1.8 B/W: 0Lux with IR on 120dB Super WDR General Shutter Time 1/100000s~1s Digital Zoom Day/Night Mode Day/Night/Auto/Customize/Schedule >55dB 7~300mm, Focal Length 42X Optical Zoom Zoom Speed Approx 7s (Wide-Tele) H43°~H2°/D53°~D2°... - Page 21 60Hz: 30fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) Secondary Stream 50Hz: 25fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180) Tertiary Stream 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180) Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG Video Bit Rate 16Kbps~16Mbps(CBR/VBR Adjustable)
- Page 22 FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Event Action Phone, PTZ Motion, HTTP Notification, etc. System Compatibility ONVIF Profile G & Q & S & T, API Working Condition Temperature: -40℃~60℃ / Humidity: 0~90%(Non-condensing) Power Supply PoE (802.3at) / AC 24V/3A±10% Power Consumption 12W MAX / 25W MAX (With IR on) Up to IP66-rated for Weather-resistant Performance /...
-
Page 23: Certifications
12. Certifications The camera has been certified for the following: CE FCC BIS IP66... -
Page 24: Disposal
13. Disposal The product referred is covered by the waste Electrical and Electronic Equipment (WEEE) directive and must be disposed of in a responsible manner. At the end of product life cycle; batteries, soldered boards, metal components and plastic components must be disposed through recyclers. If you are unable to dispose-off the products or unable to locate e-waste recyclers, you may return the product... - Page 25 MATRIX COMSEC Head Office 394-GIDC, Makarpura Vadodara – 390010, India. Phone :( +91)18002587747 E-mail: Tech.Support@MatrixComsec.com www.matrixaccesscontrol.com...
